Toyota Aygo
2014-05 → present · chassis KGB40,PAB40 · catalogue 101520 · Europe
Supported model
Data version 2018-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 16268 — Pipe, Water By-pass, NO.1 | ||||
| SU001-01095 |
Pipe, Water By-pass, NO.1
2014-05 → 2018-05
ended
|
1PP PAB40 | — | |
| 16268F — Ring, O(FOR WATER BY-PASS PIPE) | ||||
| SU001-01199 |
Ring, O(FOR WATER BY-PASS PIPE)
2014-05 → 2018-05
ended
|
1PP PAB40 | — | |
| 16268G — Gasket(FOR WATER BY-PASS PIPE) | ||||
| 16258-0Q010 |
Gasket(FOR WATER BY-PASS PIPE)
2014-05 → 2018-05
ended
|
1KRFE KGB40 | — | |
| SU001-01198 |
Gasket(FOR WATER BY-PASS PIPE)
2014-05 → 2018-05
ended
|
1PP PAB40 | — | |
| 16258-0Q010 |
Gasket(FOR WATER BY-PASS PIPE)
2018-05 → 2021-04
ended
|
1KRFE KGB40 3D | — | |
| 16258-0Q010 |
Gasket(FOR WATER BY-PASS PIPE)
2018-05 → —
|
1KRFE KGB40 | — | |
| 16258-0Q010 |
Gasket(FOR WATER BY-PASS PIPE)
2018-05 → —
|
1KRFE KGB40 5D | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
