Toyota Aygo X
2022-03 → present · chassis KGB70 · catalogue 101530 · Europe
Supported model
Data version 2022-02
Instrument Panel & Glove Compartment
32 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 50540 | DO0R Assy, Airbag Passenger |
| 55011A | Garnish Sub-assy, Instrument Panel, NO.1 |
| 55012A | Garnish Sub-assy, Instrument Panel, NO.2 |
| 55046A | Panel Sub-assy, Instrument Panel Finish, Lower LH |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55317E | Panel, Instrument Side, NO.1 |
| 55318F | Panel, Instrument Side, NO.2 |
| 55322 | Bracket, Instrument Panel, NO.1 |
| 55322A | Bracket, Instrument Panel, NO.2 |
| 55328 | Pin, Instrument Panel, NO.1 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55401F | Clip(FOR SAFETY PAD) |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55410C | Panel Assy, Instrument Cluster Finish |
| 55420A | Panel Assy, Instrument Cluster Finish, Center |
| 55421C | Hood, Meter |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55434F | Panel, Instrument Panel Finish, Lower Center |
| 55472C | Panel, Instrument Panel Speaker, NO.1 |
| 55473B | Panel, Instrument Panel Speaker, NO.2 |
| 55474A | Clip(FOR INSTRUMENT PANEL SPEAKER PANEL) |
| 55506F | Lock Sub-assy, Glove Compartment Door |
| 55524 | Cover, Switch Bace Hole |
| 55539 | Cover, Spare Switch Hole |
| 55550 | Door Assy, Glove Compartment |
| 55551A | Door, Glove Compartment, Outer |
| 55557A | Cushion, Glove Compartment Door Check |
| 55576 | Spring, Glove Compartment Door Lock, NO.1 |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
