Toyota IQ EV
2012-09 → 2012-12 · chassis KPJ10 · catalogue 104510 · Europe
Supported model
Data version 2013-10
Instrument Panel & Glove Compartment
36 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55301 | Panel Sub-assy, Instrument |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55310 | Panel Assy, Instrument, Lower |
| 55312 | Panel, Instrument, Lower |
| 55312A | Clip, Instrument Panel |
| 55317A | Panel, Instrument Side, RH |
| 55318C | Panel, Instrument Side, LH |
| 55327A | Stay, Instrument Panel, NO.2 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55349A | Cushion, Instrument Panel |
| 55352A | Brace, Instrument Panel TO Floor, NO.2 |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55355E | Cushion, Instrument Panel |
| 55356C | Cushion, Instrument Panel, NO.2 |
| 55376 | Bracket, Instrument Panel Mounting, NO.1 |
| 55394C | Bolt, Instrument Panel |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412C | Panel, Instrument Cluster Finish, Center NO.1 |
| 55414A | Panel, Instrument Cluster Finish, End |
| 55416C | Retainer, Instrument Cluster Finish Panel |
| 55421B | Panel, Instrument Cluster Finish, Upper |
| 55422C | Panel, Instrument Cluster Finish, Center Upper |
| 55434E | Cap |
| 55461A | Ornament, Instrument Panel |
| 55476C | Garnish, Instrument Panel Finish Plate |
| 55521C | Cover, Stereo Opening |
| 55521F | Cover, Stereo Opening, NO.2 |
| 55539D | Cover, Spare Switch Hole |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
