Toyota IQ EV

2012-09 → 2012-12 · chassis KPJ10 · catalogue 104510 · Europe

Supported model Data version 2013-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

15 part groups · 2 illustrations

Illustrations

Figure 743503 743503 2012-09 → — Figure 743504A 743504A 2012-09 → —

Part groups

PNCDescription
74223B Cap, Door Armrest, Front
74231 Panel, Front Armrest Base, Upper RH
74232 Panel, Front Armrest Base, Upper LH
74310 Visor Assy, RH
74317 Cover, Visor Bracket, RH
74318 Cover, Visor Bracket, LH
74320 Visor Assy, LH
74336 Clip, Visor Arm Set
74348B Holder, Visor, RH
74348C Holder, Visor, LH
74610S Grip Assy, Assist
74612D Cover, Assist Grip
74645A Cover, Door Assist Grip, RH
74646 Cover, Door Assist Grip, LH
74811B Handle, Door Pull
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
