Toyota IQ EV
2012-09 → 2012-12 · chassis KPJ10 · catalogue 104510 · Europe
Supported model
Data version 2013-10
Switch & Relay & Computer
55 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 69065A | Cylinder Sub-assy, Airbag Cut Off Switch |
| 81851C | Lamp Assy, Indicator |
| 81980 | Flasher Assy, Turn Signal |
| 82210N | Instrument Panel Fusible Link |
| 82600E | Engine Room Fuse |
| 82620A | Block Assy, Fusible Link |
| 82641 | Relay, Integration NO.1 |
| 82642A | Relay, Running Light |
| 82660B | Block Assy, Relay |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82662B | Cover, Relay Block, Upper, NO.2 |
| 82672A | Cover, Junction Block |
| 82673A | Bracket, Junction Block, NO.1 |
| 82673B | Bracket, Junction Block, NO.2 |
| 82715 | Bracket,Wiring Harness Clamp |
| 82730 | Block Assy, Instrument Panel Junction |
| 82877 | Box, Computer Integration, RH |
| 82878 | Box, Computer Integration, LH |
| 83950M | Lamp Assy, Telltale |
| 84010D | Control & Panel Assy, Integration |
| 84040 | Master Switch Assy,Multiplex Network |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84152 | Switch, Headlamp Leveling |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84247A | Switch, Steering Pad, LH |
| 84307 | Cable Sub-assy, Spiral W/Sensor |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84550 | Switch Assy, Parking Brake |
| 84650D | Switch Assy, Windshield Wiper (W/RELAY, WIPER CONTROL) |
| 84751 | Switch, Seat Heater |
| 84810 | Switch Assy, Power Window Regulator |
| 84870A | Switch Assy, Outer Mirror |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85535B | Cover, Power Outlet Socket, NO.1 |
| 85903 | Computer Sub-assy, Shift Lock Control |
| 85912 | Relay, Defogger |
| 85912G | Relay, Charge Opener |
| 85912H | Relay, Hwd, NO.1 |
| 85912J | Relay, Hwd, NO.2 |
| 85916P | Relay, Headlamp |
| 85924C | Relay, Igct |
| 85924D | Relay, Pimr |
| 85924E | Relay, Dcs |
| 85926 | Relay, Headlamp Dimmer |
| 85927 | Relay, Cooling Fan |
| 85927A | Relay, Cooling Fan, NO.2 |
| 85928B | Resistor, Cooling Fan |
| 88790F | Thermistor Assy |
| 89111 | Computer, Network Gateway |
| 89221 | Computer, Multiplex Network Body |
| 89451A | Sensor, Shift Lever Position |
| 89539E | Bracket, Computer |
| 89611 | Switch, Push Start |
| 89681A | Computer, Power Management Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
