Toyota TOYOTA1000

1969-04 → 1988-08 · chassis KP3# · catalogue 111210 · Europe

Discontinued model Data version 1988-08

Floor Pan & Lower Back Panel

40 part groups · 4 illustrations

PNC	Description
57207	Bracket Sub-assy, Engine Rear Mounting Member
57458	Member, Front Floor Cross, NO.1
57651	Crossmember, Rear Floor, Front
57652	Crossmember, Rear Floor, NO.2
57665	Panel, Lower Back Side, RH
57666	Panel, Lower Back Side, LH
57674	Bracket, Muffler Hanger Support, NO.3
57676	Bracket, Muffler Hanger Support, NO.2
57703	Bracket Sub-assy, Differential Carrier Bumper
58052	Pan Sub-assy, Center Floor
58101	Pan Sub-assy, Front Floor
58102A	Reinforcement Sub-assy, Front Floor
58123	Plate, Floor Rear Engine Mounting
58125	Brace, Floor End, RH
58126	Brace, Floor End, LH
58171	Reinforcement, Parking Brake Base
58183	Bracket, Front Seat Mounting, Inner
58185	Bracket, Accelerator Pedal Support
58186A	Bracket, Brake Tube Set
58228A	Bracket, Belt Guide
58236B	Bracket, Center Floor Heat Insulator
58286	Boot, Shift & Select Lever, NO.1
58287	Retainer, Shift Lever Boot
58305	Bracket Sub-assy, Spare Wheel Clamp
58307	Panel Sub-assy, Body Lower Back
58311	Pan, Rear Floor
58313	Panel, Rear Floor Side, RH
58314	Panel, Rear Floor Side, LH
58322	Plate, Rear Floor End
58343	Panel, Rear Floor Side, Rear RH
58344	Panel, Rear Floor Side, Rear LH
58353	Bracket, Rear Floor Tool
58355	Plate, Luggage Compartment Side, RH
58356	Plate, Luggage Compartment Side, LH
58359	Bracket, Rear Bumper Stay
58372	Panel, Body Lower Back, Inner
58379	Bracket, Luggage Door Lock Striker, Sub
58708	Carrier Sub-assy, Jack
58788	Bracket, Jack Handle Support
64292	Clamp, Jack Handle

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
