Toyota Yaris (JPP)

1999-01 → 2005-08 · chassis NCP1#,NLP10,SCP10 · catalogue 112510 · Europe

Discontinued model Data version 2006-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

18 part groups · 3 illustrations

Illustrations

Figure 745427 745427 1999-01 → — Figure 740876F 740876F 1999-01 → — Figure 742280A 742280A 2004-06 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11293C Label, Tune-up Specification Information
11294A Label, Turbocharger Information
11296C Label, Engine Service Information
16793E Label, Cooling Fan Caution
47991 Label, Brake Tube Information
69339C Label, Child Protector Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515A Plate, Theft Warning
74541E Plate, Compact Spare Tire Caution
74559A Plate, Fuel Caution
74559B Label, Fuel Information
74567A Plate, E.C.E Approved Number
74596A Label, Side Airbag Caution
74751 Label, Tire Pressure Information
87529B Label, A/C Filter Information
88723J Label, Cooler Service Caution, NO.2
C6177 Label, Heater Notice
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
