Toyota Yaris (FRP)

2001-01 → 2005-11 · chassis SCP1#,NLP10 · catalogue 116510 · Europe

Discontinued model Data version 2006-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Electronic Controled Diesel (ECD)

7 part groups · 2 illustrations

Illustrations

Figure 845465 845465 2003-02 → — Figure 845466 845466 2003-02 → —

Part groups

PNCDescription
85915B Relay, Main (FOR DIESEL TURBO)
89279B Cover, Diesel Engine Control Computor
89422C Sensor, Diesel Engine Water Temperature
89661A Computer, Engine Control
89667A Bracket, Engine Control Computer, NO.1
89668A Bracket, Engine Control Computer, NO.2
89669B Bracket, Engine Control Computer, NO.3
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
