Toyota Yaris (FRP)

2005-11 → 2011-07 · chassis KSP90,NLP90,NSP90,SCP90 · catalogue 116520 · Europe

Supported model Data version 2012-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

17 part groups · 3 illustrations

Illustrations

Figure 745442A 745442A 2005-11 → — Figure 741761E 741761E 2005-11 → — Figure 741762G 741762G 2005-11 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11289B Label, Spark Plug Notice
11295B Label, Engine Service Notice, NO.1
11296C Label, Engine Service Information
15369A Label, Engine Oil Information
16793E Label, Cooling Fan Caution
74515A Plate, Theft Warning
74529 Plate, Child Proof OR Child Protector Lock Caution
74559B Label, Fuel Information
74567A Plate, E.C.E Approved Number
74596A Label, Side Airbag Caution
74598A Label, Passenger Airbag Caution
74751 Label, Tire Pressure Information
87529B Label, A/C Filter Information
88723J Label, Cooler Service Caution, NO.2
89616 Label, Push Start Information
C6177 Label, Heater Notice
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
