Toyota Urban Cruiser
2009-01 → 2016-04 · chassis NLP11#,NSP110 · catalogue 117520 · Europe
Supported model
Data version 2016-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 25601 — Pipe Sub-assy, Egr, NO.1 | ||||
| 25611-47010 |
Pipe Sub-assy, Egr, NO.1
2009-01 → 2010-07
ended
|
1NRFE NSP110 | — | |
| 25611-47011 |
Pipe Sub-assy, Egr, NO.1
2010-07 → —
|
1NRFE NSP110 | — | |
| 25620 — Valve Assy, Egr | ||||
| 25620-47020 |
Valve Assy, Egr
2009-01 → —
|
1NRFE NSP110 | — | |
| 25620A — Bolt, Stud(FOR EGR VALVE) | ||||
| 90126-08052 |
Bolt, Stud(FOR EGR VALVE)
2009-01 → 2010-02
ended
|
1NRFE NSP110 | — | |
| 90126-08063 |
Bolt, Stud(FOR EGR VALVE)
2010-02 → —
|
1NRFE NSP110 | — | |
| 25627C — Gasket(FOR EGR PIPE NO.2) | ||||
| 25629-47010 |
Gasket(FOR EGR PIPE NO.2)
2009-01 → —
|
1NRFE NSP110 | — | |
| 25633 — Gasket, Egr Valve | ||||
| 25633-47010 |
Gasket, Egr Valve
2009-01 → —
|
1NRFE NSP110 | — | |
| 25634 — Gasket, Egr Pipe | ||||
| 25634-33010 |
Gasket, Egr Pipe
2009-01 → 2014-05
ended
|
1NDTV NLP11# | — | |
| 25634-47010 |
Gasket, Egr Pipe
2009-01 → —
|
1NRFE NSP110 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
