Toyota Yaris GR

2020-08 → present · chassis GXPA16 · catalogue 11E210 · Europe

Supported model Data version 2024-10

Front Door Panel & Glass

38 part groups · 2 illustrations

PNC	Description
67001	Panel Sub-assy, Front Door, RH
67002	Panel Sub-assy, Front Door, LH
67211G	Stop, Front Door Window, Upper
67235C	Stabilizer, Door Glass Female, RH
67236C	Stabilizer, Door Glass Female, LH
67401F	Frame Sub-assy, Front Door, Front Lower RH
67402F	Frame Sub-assy, Front Door, Front Lower LH
67491A	Garnish, Front Door Lower Frame Bracket, RH
67492A	Garnish, Front Door Lower Frame Bracket, LH
67533E	Seal, Front Door Division Bar, RH
67534E	Seal, Front Door Division Bar, LH
67601	Board Sub-assy, Front Door Trim, RH
67601B	Clip(FOR FRONT DOOR TRIM BOARD)
67601L	Clip(FOR FRONT DOOR TRIM BOARD)
67602	Board Sub-assy, Front Door Trim, LH
67655	Garnish, Front Door Trim, RH
67656	Garnish, Door Trim, LH
67831	Cover, Front Door Service Hole, RH
67831D	Clip(FOR FRONT DOOR SERVICE HOLE COVER)
67832	Cover, Front Door Service Hole, LH
67837B	Seal, Front Door Dust Proof
67861	Weatherstrip, Front Door, RH
67862	Weatherstrip, Front Door, LH
67867C	Retainer, Front Door Weatherstrip, RH
67867G	Retainer, Door Weatherstrip, RH
67868C	Retainer, Front Door Weatherstrip, LH
67868R	Retainer, Front Door Weatherstrip, LH
67869B	Clip, Front Door Weatherstrip
67869E	Clip, Front Door Weatherstrip
68101	Glass Sub-assy, Front Door, RH
68102	Glass Sub-assy, Front Door, LH
68141C	Run, Front Door Glass, RH
68151C	Run, Front Door Glass, LH
68160C	Weatherstrip Assy, Front Door Glass, Outer RH
68171B	Weatherstrip, Front Door Glass, Inner RH
68172A	Weatherstrip, Front Door Glass, Inner LH
68210C	Weatherstrip Assy, Front Door Glass, Outer LH
68610	Check Assy, Front Door

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
