Toyota Starlet
1989-12 → 1996-01 · chassis EP8#,NP80 · catalogue 121540 · Europe
Discontinued model
Data version 1996-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83390B — Hose, Vacuum(FOR ECONOMETER) | ||||
| 90999-92002 note |
Hose, Vacuum(FOR ECONOMETER)
1989-12 → 1992-01
ended
|
EP8# LHD CBR | — | |
| 90999-92002 note |
Hose, Vacuum(FOR ECONOMETER)
1989-12 → 1992-01
ended
|
EP80 LHD | — | |
| 90999-92002 note |
Hose, Vacuum(FOR ECONOMETER)
1989-12 → 1992-01
ended
|
EP81 (3FC,5F) EFI | — | |
| 90999-92002 note |
Hose, Vacuum(FOR ECONOMETER)
1992-01 → 1994-05
ended
|
EP81 LHD EFI | — | |
| 90999-92002 note |
Hose, Vacuum(FOR ECONOMETER)
1992-01 → 1994-05
ended
|
EP81 LHD EFI | — | |
| 83390C — Union(FOR ECONOMETER) | ||||
| 90413-04001 |
Union(FOR ECONOMETER)
1989-12 → 1992-01
ended
|
EP80 LHD;EP81 (3FC,5F) EFI | — | |
| 90413-04001 |
Union(FOR ECONOMETER)
1992-01 → 1994-05
ended
|
EP81 LHD EFI | — | |
| 83391D — Switch, Vacuum | ||||
| 83391-20060 |
Switch, Vacuum
1989-12 → 1992-01
ended
|
EP81 (3FC,5F) XLI;EP8# LHD +1 | — | |
| 83391-20060 |
Switch, Vacuum
1992-01 → 1994-05
ended
|
EP81 LHD EFI | — | |
| 83399B — Bracket, Vacuum Switch | ||||
| 83399-10040 |
Bracket, Vacuum Switch
1989-12 → 1992-01
ended
|
EP8# LHD CBR | — | |
| 83399-10060 |
Bracket, Vacuum Switch
1989-12 → 1994-05
ended
|
EP81 LHD (3FC,5F) EFI | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
