Toyota Tercel

1979-01 → 1982-04 · chassis AL1# · catalogue 131210 · Europe

Discontinued model Data version 1982-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Transmission Case & Oil Pan (ATM)

18 part groups · 2 illustrations

Illustrations

Figure MC6433B MC6433B 1979-08 → — Figure MC6434C MC6434C 1979-08 → —

Part groups

PNCDescription
35013 Tube Sub-assy, Transmission Oil Filler
35101E Pin, Straight (FOR AUTOMATIC TRANSMISSION CASE)
35103 Gage Sub-assy, Transmission Oil Level
35104 Case Sub-assy, Automatic Transmission
35104A Plug, Automatic Transmission Case
35104B Plug, Breather, NO.1 (ATM)
35106 Pan Sub-assy, Automatic Transmission Oil
35106A Plug Sub-assy, Drain (ATM)
35106B Gasket, Drain Plug (ATM)
35111Y Ring, O (FOR AUTOMATIC TRANSMISSION CASE)
35118 Plate, Stifener, RH (ATM)
35119 Plate, Stifener, LH (ATM)
35142 Gasket, Transmission Case(ATM)
35148 Gasket, Governor Apply, NO.1
35168 Gasket, Automatic Transmission Oil Pan
35194A Cover, Transmission Case Dust
35336 Ring, O (FOR TRANSMISSION OIL FILLER TUBE)
35394 Magnet, Oil Cleaner (FOR TRANSMISSION)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
