Toyota Tercel
1982-05 → 1988-01 · chassis AL2# · catalogue 131220 · Europe
Discontinued model
Data version 1988-05
Headlamp
27 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 04817 | Headlamp Kit, W/O Sealed Beam, RH |
| 04818 | Headlamp Kit, W/O Sealed Beam, LH |
| 81110 | Headlamp Assy, RH |
| 81110B | Bulb(FOR HEADLAMP, NO.1) |
| 81110S | Sealed Beam Unit, NO.1 |
| 81111A | Ring, Sealed Beam Retaining, NO.1 RH |
| 81113 | Ring, Sealed Beam Mounting, NO.1 RH |
| 81115A | Body And Reflector Sub-assy, Headlamp, RH |
| 81116A | Body And Reflector Sub-assy, Headlamp, LH |
| 81117 | Packing, Headlamp Housing |
| 81118 | Nut, Spring |
| 81119 | Screw, Headlamp |
| 81120 | Headlamp Sub-assy, RH |
| 81121 | Spring, Headlamp Tension |
| 81131 | Screw, Headlamp Adjusting |
| 81135 | Unit Assy, Headlamp, RH |
| 81136A | Rim, Headlamp, RH |
| 81138 | Spring, Headlamp |
| 81144 | Cover, Headlamp, NO.1 |
| 81146 | Lens, Headlamp, RH |
| 81150 | Headlamp Assy, LH |
| 81151A | Ring, Sealed Beam Retaining, NO.1 LH |
| 81153 | Ring, Sealed Beam Mounting, NO.1 LH |
| 81160 | Headlamp Sub-assy, LH |
| 81175 | Unit Assy, Headlamp, LH |
| 81176A | Rim, Headlamp, LH |
| 81186 | Lens, Headlamp, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
