Toyota Paseo
1995-08 → 1999-07 · chassis EL54 · catalogue 144220 · Europe
Discontinued model
Data version 2000-02
Seat Belt & Child Restraint Seat
19 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 73003A | Belt Set, Rear Seat 3 Point Type, RH |
| 73004A | Belt Set, Rear Seat 3 Point Type, LH |
| 73201C | Bar Sub-assy, Front Seat Belt, Outer RH |
| 73202B | Bar Sub-assy, Front Seat Belt, Outer LH |
| 73203 | Belt Set, Front Seat, RH |
| 73204A | Belt Set, Front Seat, LH |
| 73208 | Cover Sub-assy, FR Seat Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73317 | Cap, Rear Seat Belt, RH |
| 73318 | Cap, Rear Seat Belt, LH |
| 73360 | Belt Assy, Rear Seat 3 Point Type, Outer RH |
| 73370 | Belt Assy, Rear Seat 3 Point Type, Outer LH |
| 73380 | Belt Assy, Rear Seat 3 Point Type, Inner, RH |
| 73390 | Belt Assy, Rear Seat 3 Point Type, Inner, LH |
| 73439 | Cushion, Rear Seat Belt Retractor |
| 73709 | Bracket Sub-assy, Tether Anchor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
