Toyota Corolla HB

1987-05 → 1992-11 · chassis EE90,AE92,CE90 · catalogue 153520 · Europe

Discontinued model Data version 1993-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes
Exploded illustration NB0059 75998B — STRIPE, REAR BUMPER SIDE, RH (14 parts) 75973D — STRIPE, FRONT BUMPER SIDE, RH (14 parts) 75974D — STRIPE, FRONT BUMPER SIDE, LH (14 parts) 75999B — STRIPE, REAR BUMPER SIDE, LH (14 parts) 75987 — STRIPE, REAR DOOR, RH (9 parts) 75988 — STRIPE, REAR DOOR, LH (9 parts)
NB0059 · 6 callouts Full size ↗
74 parts on this figure
Part number Description Fitment Price
75973D — Stripe, Front Bumper Side, RH
75972-12020 note Stripe, Front Bumper Side, RH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1987-05 → 1988-08 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Front Bumper Side, RH
1987-05 → 1988-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1991-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1991-06 → 1991-08 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1989-08 → 1991-06 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1988-10 → 1989-08 ended
AE92 5D;AE92 3D XL;EE90 +5 —
75998-12080-02 note Stripe, Front Bumper Side, RH
1988-10 → 1989-08 ended
AE92,EE90 LHD 3D GL —
75998-12080-02 note Stripe, Front Bumper Side, RH
1988-10 → 1989-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Front Bumper Side, RH
1988-08 → 1988-10 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Front Bumper Side, RH
1988-08 → 1988-10 ended
AE92 EFI —
75998-12080-03 note Stripe, Front Bumper Side, RH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-04 note Stripe, Front Bumper Side, RH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-05 note Stripe, Front Bumper Side, RH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75974D — Stripe, Front Bumper Side, LH
75972-12020 note Stripe, Front Bumper Side, LH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1988-10 → 1989-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1991-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1991-06 → 1991-08 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1989-08 → 1991-06 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1988-10 → 1989-08 ended
AE92 5D;AE92 3D XL;EE90 +5 —
75998-12080-02 note Stripe, Front Bumper Side, LH
1988-10 → 1989-08 ended
AE92,EE90 LHD 3D GL —
75998-12080-02 note Stripe, Front Bumper Side, LH
1988-08 → 1988-10 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Front Bumper Side, LH
1988-08 → 1988-10 ended
AE92 EFI —
75998-12080-02 note Stripe, Front Bumper Side, LH
1987-05 → 1988-08 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Front Bumper Side, LH
1987-05 → 1988-08 ended
AE92 EFI —
75998-12080-03 note Stripe, Front Bumper Side, LH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-04 note Stripe, Front Bumper Side, LH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-05 note Stripe, Front Bumper Side, LH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75987 — Stripe, Rear Door, RH
75987-12190-03 note Stripe, Rear Door, RH
1988-08 → 1989-08 ended
AE92 EFI —
75987-12190-03 note Stripe, Rear Door, RH
1991-08 → 1992-11 ended
AE92 GTI —
75987-12190-03 note Stripe, Rear Door, RH
1989-08 → 1991-08 ended
AE92 GTI —
75987-12190-03 note Stripe, Rear Door, RH
1987-05 → 1988-08 ended
AE92 EFI —
75987-12190-13 note Stripe, Rear Door, RH
1988-10 → 1989-08 ended
AE92 EFI —
75987-12190-13 note Stripe, Rear Door, RH
1989-08 → 1991-06 ended
AE92 GTI —
75987-12190-13 note Stripe, Rear Door, RH
1991-06 → 1991-08 ended
AE92 GTI —
75987-12190-13 note Stripe, Rear Door, RH
1987-05 → 1988-10 ended
AE92 EFI —
75987-12190-13 note Stripe, Rear Door, RH
1991-08 → 1992-11 ended
AE92 GTI —
75988 — Stripe, Rear Door, LH
75987-12190-03 note Stripe, Rear Door, LH
1987-05 → 1988-08 ended
AE92 EFI —
75987-12190-03 note Stripe, Rear Door, LH
1991-08 → 1992-11 ended
AE92 GTI —
75987-12190-03 note Stripe, Rear Door, LH
1989-08 → 1991-08 ended
AE92 GTI —
75987-12190-03 note Stripe, Rear Door, LH
1988-08 → 1989-08 ended
AE92 EFI —
75987-12190-13 note Stripe, Rear Door, LH
1989-08 → 1991-06 ended
AE92 GTI —
75987-12190-13 note Stripe, Rear Door, LH
1991-06 → 1991-08 ended
AE92 GTI —
75987-12190-13 note Stripe, Rear Door, LH
1987-05 → 1988-10 ended
AE92 EFI —
75987-12190-13 note Stripe, Rear Door, LH
1991-08 → 1992-11 ended
AE92 GTI —
75987-12190-13 note Stripe, Rear Door, LH
1988-10 → 1989-08 ended
AE92 EFI —
75998B — Stripe, Rear Bumper Side, RH
75972-12020 note Stripe, Rear Bumper Side, RH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1988-08 → 1988-10 ended
AE92 EFI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1987-05 → 1988-08 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1991-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1987-05 → 1988-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1991-06 → 1991-08 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1989-08 → 1991-06 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1988-10 → 1989-08 ended
AE92 5D;AE92 3D XL;EE90 +5 —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1988-10 → 1989-08 ended
AE92,EE90 LHD 3D GL —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1988-10 → 1989-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Rear Bumper Side, RH
1988-08 → 1988-10 ended
AE92,CE90,EE90 GL,XL —
75998-12080-03 note Stripe, Rear Bumper Side, RH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-04 note Stripe, Rear Bumper Side, RH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-05 note Stripe, Rear Bumper Side, RH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75999B — Stripe, Rear Bumper Side, LH
75972-12020 note Stripe, Rear Bumper Side, LH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1991-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1991-06 → 1991-08 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1989-08 → 1991-06 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1988-10 → 1989-08 ended
AE92 5D;AE92 3D XL;EE90 +5 —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1988-10 → 1989-08 ended
AE92,EE90 LHD 3D GL —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1988-10 → 1989-08 ended
AE92 EFI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1988-08 → 1988-10 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1988-08 → 1988-10 ended
AE92 EFI —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1987-05 → 1988-08 ended
AE92,CE90,EE90 GL,XL —
75998-12080-02 note Stripe, Rear Bumper Side, LH
1987-05 → 1988-08 ended
AE92 EFI —
75998-12080-03 note Stripe, Rear Bumper Side, LH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-04 note Stripe, Rear Bumper Side, LH
1987-05 → 1989-08 ended
AE92,CE90,EE90 GL,GTI,XL —
75998-12080-05 note Stripe, Rear Bumper Side, LH
1989-08 → 1992-11 ended
AE92,CE90,EE90 GL,GLI,GTI,SR5,XL,XLI —
No quantity column: the factory catalogue records which parts a vehicle takes, never how many.
