Toyota Corolla HB
1987-05 → 1992-11 · chassis EE90,AE92,CE90 · catalogue 153520 · Europe
Discontinued model
Data version 1993-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 85341R — Nozzle Assy, Washer | ||||
| 85341-12230 |
Nozzle Assy, Washer
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 85348R — Joint, Rear Washer Hose, NO.1 | ||||
| 85349-89122 |
Joint, Rear Washer Hose, NO.1
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 85348T — Joint, Rear Washer Hose, NO.2 | ||||
| 85355-20080 |
Joint, Rear Washer Hose, NO.2
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 85372R — Hose, Rear Washer (FROM JOINT TO JOINT OR NOZZLE) | ||||
| 90099-33299 note |
Hose, Rear Washer (FROM JOINT TO JOINT OR NOZZLE)
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 90099-33852 note |
Hose, Rear Washer (FROM JOINT TO JOINT OR NOZZLE)
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 85372T — Grommet, Washer | ||||
| 85372-12020 |
Grommet, Washer
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
| 85373R — Hose, Rear Washer (FROM JOINT TO NOZZLE) | ||||
| 90099-33299 note |
Hose, Rear Washer (FROM JOINT TO NOZZLE)
1987-05 → 1992-11
ended
|
AE92,CE90,EE90 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
