Toyota Corolla HB/LB

1997-05 → 2001-11 · chassis AE111,CDE110,CE110,EE111,WZE110,ZZE11# · catalogue 153540 · Europe

Discontinued model Data version 2002-04

Manifold

43 part groups · 7 illustrations

PNC	Description
15407A	Bolt, Union(FOR TURBO OIL INLET PIPE)
15407B	Gasket(FOR TURBO OIL INLET PIPE)
15472	Gasket, Turbo Oil Outlet, NO.1
15474	Pipe, Turbo Oil Outlet
15474A	Hose, Turbo Oil Outlet
15474B	Clamp OR Clip(FOR TURBO OIL OUTLET HOSE)
15476	Pipe, Turbo Oil Outlet, NO.2
15477	Pipe, Turbo Oil Inlet
16581D	Clamp, Hose(FOR WATER HOSE)
17021	Housing Sub-assy, Bearing
17021A	Bolt, Stud(FOR BEARING HOUSING)
17024	Housing Sub-assy, Compressor
17111	Manifold, Intake
17114B	Gasket, Intake Flange
17118	Stay, Manifold
17119	Stay, Manifold, NO.2
17125	Stay, Surge Tank, NO.1
17129	Tank, Intake Air Surge
17141	Manifold, Exhaust
17141B	Collar(FOR EXHAUST MANIFOLD)
17141K	Bolt, Stud(FOR EXHAUST MANIFOLD TO CYLINDER HEAD)
17152	Bolt, Stud(FOR MANIFOLD TO EXHAUST PIPE)
17159	Bolt, Stud(FOR MANIFOLD TO CYLINDER HEAD)
17167	Insulator, Exhaust Manifold Heat, NO.1
17168	Insulator, Exhaust Manifold Heat, NO.2
17173	Gasket, Exhaust Manifold TO Head
17177	Gasket, Intake Manifold TO Head, NO.1
17179A	Gasket, Intake Manifold, NO.2
17201	Turbocharger Sub-assy
17229	Band, V
17230	Actuator Assy, W/Bracket
17246	Plate, Compressor Housing Clamp
17271	Insulator, Turbo, NO.1
17272	Insulator, Turbo, NO.2
17278	Gasket, Turbo TO Exhaust Manifold
17279	Gasket, Turbine Outlet Elbow
17293	Stay, Turbocharger
17294	Hose, Actuator
17294A	Clip(FOR ACTUATOR HOSE)
17861F	Connector, Intake Air
25508	Converter Sub-assy, Manifold
25591	Bracket, Manifold Support
26100F	Shutter Assy, Intake

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
