Toyota Corolla HB/LB
1997-05 → 2001-11 · chassis AE111,CDE110,CE110,EE111,WZE110,ZZE11# · catalogue 153540 · Europe
Discontinued model
Data version 2002-04
Accelerator Link
17 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 78024 | Bracket Sub-assy, Accelerator Control Cable |
| 78110A | Spring (FOR ACCELERATOR PEDAL ROD) |
| 78110C | Bush (FOR ACCELERATOR PEDAL ROD) |
| 78110J | Spring (FOR ACCELERATOR PEDAL ROD) |
| 78111 | Pedal, Accelerator |
| 78111A | Spring (FOR ACCELERATOR PEDAL) |
| 78111C | Pin (FOR ACCELERATOR PEDAL) |
| 78120G | Rod Assy, Accelerator Pedal |
| 78180P | Cable Assy, Accelerator Control |
| 78183B | Clamp, Accelerator Control Cable |
| 78183C | Clamp, Accelerator Control Cable |
| 78183D | Clamp, Accelerator Control Cable |
| 78184B | Bracket, Accelerator Control Cable |
| 78186 | Support, Accelerator Control Cable, NO.1 |
| 78186B | Support, Accelerator Control Cable NO.2 |
| 78188D | Damper, Accelerator Pull Back Spring |
| 78189A | Support, Accelerator Control Cable, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
