Toyota Corolla Verso
2004-02 → 2009-02 · chassis AUR10,CUR10,ZNR1# · catalogue 157230 · Europe
Supported model
Data version 2009-07
Instrument Panel & Glove Compartment
55 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 50540 | DO0R Assy, Airbag Passenger |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55303B | Panel Sub-assy, Instrument, Lower |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55308C | Bracket Sub-assy, Instrument Panel, Center |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55343B | Brace, Instrument Panel TO Cowl, Center |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55356C | Cushion, Instrument Panel, NO.2 |
| 55357B | Cushion, Instrument Panel, NO.3 |
| 55358K | Cushion, Instrument Panel, NO.4 |
| 55359D | Cushion, Instrument Panel, NO.5 |
| 55362B | Bracket, Meter, Lower |
| 55368C | Bracket, Meter Mounting |
| 55374C | Bracket, Instrument Panel Lower Mounting, NO.1 |
| 55403 | Hood Sub-assy, Meter |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55417B | Retainer, Radio Tuner Finish |
| 55420A | Panel Assy, Instrument Cluster Finish, Center |
| 55423E | Cushion, Center Cluster, NO.1 |
| 55425B | Reinforcement, Instrument Cluster Finish Panel |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55440D | Box Assy, Instrument Panel |
| 55443D | Knob, Instrument Panel Box Door |
| 55444A | Spring, Instrument Panel Box |
| 55445J | Spring, Instrument Panel Box |
| 55446A | Base, Switch Hole, NO.1 |
| 55447C | Base, Switch Hole, NO.2 |
| 55510 | Door Assy, Glove Compartment |
| 55511 | Door, Glove Compartment |
| 55521C | Cover, Stereo Opening |
| 55538A | Cover, Cooler Switch Hole |
| 55539 | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55548A | Cover, Instrument Panel Hole |
| 55550 | Door Assy, Glove Compartment |
| 55560A | Lock Assy, Glove Compartment Door |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 58808B | Cover, Shifting Hole |
| 58843A | Bezel, Shifting Hole |
| 58848B | Cover, Shift Lever Hole |
| 69065 | Cylinder Sub-assy, Airbag Cut Off SW |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 81942C | Sheet, Heater Control Name |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
