Toyota Verso

2009-02 → 2017-10 · chassis AUR2#,WAR20,ZGR2# · catalogue 157240 · Europe

Supported model Data version 2018-04

Manifold

45 part groups · 8 illustrations

PNC	Description
04175	Gasket Kit, Turbocharger
12635	Joint, Engine Cover
15407B	Gasket(FOR TURBO OIL INLET PIPE)
15471	Gasket, Turbo Oil Inlet
15472	Gasket, Turbo Oil Outlet, NO.1
15474	Pipe, Turbo Oil Outlet
15474A	Hose, Turbo Oil Outlet
15476	Pipe, Turbo Oil Outlet, NO.2
15481	Pipe, Turbo Oil, NO.1
15481A	Bolt, Union, NO.1
15481B	Gasket(FOR UNION BOLT NO.1)
15482	Pipe, Turbo Oil, NO.2
15482A	Bolt, Union, NO.2
15482B	Gasket(FOR UNION BOLT NO.2)
17111	Manifold, Intake
17111Z	Bolt, Stud(FOR INTAKE MANIFOLD TO CYLINDER HEAD)
17112	Manifold, Intake, NO.2
17114B	Gasket, Intake Flange
17118	Stay, Manifold
17119	Stay, Manifold, NO.2
17138B	Stay, Intake Manifold
17139	Stay, Manifold, NO.2
17141	Manifold, Exhaust
17159	Bolt, Stud(FOR MANIFOLD TO CYLINDER HEAD)
17167	Insulator, Exhaust Manifold Heat, NO.1
17168	Insulator, Exhaust Manifold Heat, NO.2
17173	Gasket, Exhaust Manifold TO Head
17177	Gasket, Intake Manifold TO Head, NO.1
17191	Pipe, Exhaust Manifold, NO.1
17201	Turbocharger Sub-assy
17229	Band, V
17271	Insulator, Turbo, NO.1
17278	Gasket, Turbo TO Exhaust Manifold
17279	Gasket, Turbine Outlet Elbow
17293	Stay, Turbocharger
17853B	Insulator, Intake Manifold
22271A	Gasket, Throttle Body
25051	Converter Sub-assy, Exhaust Manifold
25509	Insulator Sub-assy, Manifold Convertor
25586	Insulator, Manifold Converter, NO.1
25587	Insulator, Manifold Converter, NO.2
25589	Insulator, Manifold Converter, NO.4
25612A	Pipe, Egr, NO.2
25686B	Gasket, Egr Cooler, NO.2
25761D	Hose, Vaccum Transmitting, NO.1

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
