Toyota Corolla/Trueno

1974-08 → 1981-07 · chassis KE3#,5#,TE3#,47,51 · catalogue 161230 · Europe

Discontinued model Data version 1981-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Mirror

13 part groups · 2 illustrations

Illustrations

Figure ME4876F ME4876F 1974-08 → — Figure ME7109C ME7109C 1974-08 → —

Part groups

PNCDescription
87810 Mirror Assy, Inner Rear View
87816 Spring, Inner Rear View Mirror
87827 Absorber, Inner Rear View Mirror
87829 Holder, Inner Rear View Mirror Stay
87834 Cover, Inner Rear View Mirror Stay Holder
87910 Mirror Assy, Outer Rear View, RH
87910K Gasket Kit, Outer Rear View Mirror, RH
87911 Gasket, Outer Rear View Mirror, RH
87928 Retainer, Outer Rear View Mirror, RH
87929 Retainer, Outer Rear View Mirror, LH
87940 Mirror Assy, Outer Rear View, LH
87940K Gasket Kit, Outer Rear View Mirror, LH
87941 Gasket, Outer Rear View Mirror, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
