Toyota Corolla Sed (JPP)
2006-11 → 2013-04 · chassis ADE150,NDE150,NRE150,ZRE151,ZZE150 · catalogue 162510 · Europe
Supported model
Data version 2013-10
Side Member
56 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 55713C | Panel, Cowl Top Side, RH |
| 55714C | Panel, Cowl Top Side, LH |
| 58745 | Protector, Quarter Panel, Front RH |
| 58746 | Protector, Quarter Panel, Front LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61061 | Reinforcement Sub-assy, Wheel House, RH |
| 61062 | Reinforcement Sub-assy, Wheel House, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61128 | Reinforcement, Cowl Side Panel, RH |
| 61129 | Reinforcement, Cowl Side Panel, LH |
| 61131C | Pillar, Front Body, Outer RH |
| 61132B | Pillar, Front Body, Outer LH |
| 61201 | Rail Sub-assy, Roof Side, RH |
| 61202 | Rail Sub-assy, Roof Side, LH |
| 61203 | Rail Sub-assy, Roof Side, Inner RH |
| 61204 | Rail Sub-assy, Roof Side, Inner LH |
| 61211C | Rail, Roof Side, RH |
| 61212C | Rail, Roof Side, LH |
| 61305 | Reinforce Sub-assy, Center Body Pillar, Lower RH |
| 61306 | Reinforce Sub-assy, Center Body Pillar, Lower LH |
| 61311C | Panel, Rear Body Front Outside, RH |
| 61312C | Panel, Rear Body Front Outside, LH |
| 61418A | Reinforcement, Rocker Panel, RH |
| 61419A | Reinforcement, Rocker Panel, LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61633A | Panel, Quarter Wheel House, Inner RH |
| 61634A | Panel, Quarter Wheel House, Inner LH |
| 61697D | Housing, Quarter Panel End, RH |
| 61698D | Housing, Quarter Panel End, LH |
| 61711 | Panel, Roof Side, Outer RH |
| 61712 | Panel, Roof Side, Outer LH |
| 61731B | Panel, Roof Side, Inner RH |
| 61732B | Panel, Roof Side, Inner LH |
| 61735A | Panel, Roof Side, Inner Rear RH |
| 61736A | Panel, Roof Side, Inner Rear LH |
| 61737D | Reinforcement, Roof Side, Inner RH |
| 61738D | Reinforcement, Roof Side, Inner LH |
| 61951 | Bracket, Side Trim, RH |
| 61952 | Bracket, Side Trim, RH |
| 62152B | Pad, Cowl Side Silencer, NO.2 |
| 62554B | Pad, Pillar, NO.4 |
| 64304B | Reinforce Sub-assy, Package Tray Bracket, RH |
| 64305B | Reinforce Sub-assy, Package Tray Bracket, LH |
| 65631C | Plate, Rear Wheel House, Front RH |
| 65632B | Plate, Rear Whell House, Front LH |
| 65637 | Liner, Rear Wheel House, RH |
| 65638 | Liner, Rear Wheel House, LH |
| 75941A | Stripe, Center Pillar, RH |
| 75942B | Stripe, Center Pillar, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
