Toyota Corolla (UKP)
2019-01 → present · chassis MZEH1#,NRE210,ZWE21# · catalogue 166230 · Europe
Supported model
Data version 2022-12
Deck Board & Deck Trim Cover
47 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 58331H | Bracket, Luggage Compartment Trim, NO.1 |
| 58332K | Bracket, Luggage Compartment Trim, NO.2 |
| 58337A | Bracket, Deck Side Trim, RH |
| 58338B | Bracket, Deck Side Trim, LH |
| 58401E | Board Sub-assy, Deck |
| 58410B | Board Assy, Deck |
| 58415E | Board, Rear Floor, NO.1 |
| 58418 | Bracket, Deck Board, NO.1 |
| 58419 | Bracket, Deck Board, NO.2 |
| 58460D | Striker Assy, Luggage Hold Belt |
| 58460J | Striker Assy, Luggage Hold Belt |
| 58470C | Handle Assy, Deck Board |
| 58570A | Mat Assy, Rear Floor |
| 61624G | Bracket, Deck Side Trim Upper, RH |
| 61627G | Bracket, Deck Side Trim Upper, LH |
| 64070A | Box Assy, Deck Floor, Front |
| 64230 | Net Assy, Room Partition |
| 64306 | Suspender Sub-assy, Package Tray Trim |
| 64330D | Panel Assy, Package Tray Trim |
| 64429A | Box, Luggage Compartment Trim |
| 64714E | Clip(FOR DECK TRIM SIDE COVER) |
| 64716D | Cover, Deck Trim, Rear |
| 64716E | Clip(FOR DECK TRIM REAR COVER) |
| 64718A | Cover, Deck Trim Service Hole |
| 64726B | Clip, Deck Rear Trim |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 64730E | Clip(FOR DECK TRIM SIDE BOARD) |
| 64730H | Clip(FOR DECK TRIM SIDE PANEL) |
| 64730K | Clip(FOR DECK SIDE TRIM PANEL) |
| 64733B | Board, Deck Trim Side, Upr RH |
| 64734B | Board, Deck Trim Side, Upper LH |
| 64740C | Panel Assy, Deck Trim Side, LH |
| 64741B | Box, Deck Side Trim, RH |
| 64742C | Box, Deck Side Trim, LH |
| 64743A | Board, Deck Trim Side, Lower RH |
| 64744 | Board, Deck Trim Side, Lower LH |
| 64750G | Garnish Assy, Deck Side, Rear RH |
| 64777J | Cushion, Spare Wheel |
| 64779B | Stopper, Spare Wheel Cover |
| 64779K | Stopper, Spare Wheel Cover |
| 64910J | Cover Assy, Tonneau |
| 64933A | Bracket, Tonneau Cover Holder, RH |
| 64934A | Bracket, Tonneau Cover Holder, LH |
| 64991 | Box, Deck Floor, Front |
| 64995 | Box, Deck Floor, RH |
| 64997 | Box, Deck Floor, LH |
| 64997C | Clip(FOR DECK FLOOR BOX) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
