Toyota Auris/Hybrid (UKP)
2007-02 → 2013-05 · chassis ADE15#,NDE150,NRE150,ZRE15#,ZZE150,ZWE150 · catalogue 166510 · Europe
Supported model
Data version 2014-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| G9282 — Thermistor, Hybrid Battery | ||||
| G9282-47060 |
Thermistor, Hybrid Battery
2010-06 → 2012-10
ended
|
ZWE150 | — | |
| G9510 — Battery Assy, HV Supply | ||||
| G9510-12010 |
Battery Assy, HV Supply
2010-06 → —
|
ZWE150 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
