Toyota Carina
1970-12 → 1977-07 · chassis TA1# · catalogue 221210 · Europe
Discontinued model
Data version 1977-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 21015 — Housing Sub-assy, Coil | ||||
| 21015-25181 |
Housing Sub-assy, Coil
1975-10 → 1977-01
ended
|
2T TA14 | — | |
| 21015-26400 |
Housing Sub-assy, Coil
1977-01 → 1977-07
ended
|
2T TA14 | — | |
| 21015-40012 |
Housing Sub-assy, Coil
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21112 — Horn, Air | ||||
| 21112-25010 |
Horn, Air
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21112-25011 |
Horn, Air
1972-08 → 1973-04
ended
|
T,2T TA1# | — | |
| 21112-25012 |
Horn, Air
1973-04 → 1975-09
ended
|
T,2T TA1# | — | |
| 21112-26041 note |
Horn, Air
1972-08 → 1973-04
ended
|
2TB TA12 | — | |
| 21112-26042 note |
Horn, Air
1973-04 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21112-26051 note |
Horn, Air
1972-08 → 1973-04
ended
|
2TB TA12 | — | |
| 21112-26052 note |
Horn, Air
1973-04 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21112-26350 |
Horn, Air
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21121 — Case, Thermostat | ||||
| 21121-34061 |
Case, Thermostat
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21121-34080 |
Case, Thermostat
1972-08 → 1975-09
ended
|
T,2T TA1# | — | |
| 21121-38010 |
Case, Thermostat
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21205 — Jet Sub-assy, Slow | ||||
| 21205-26040 note |
Jet Sub-assy, Slow
1972-08 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21205-33010 note |
Jet Sub-assy, Slow
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 90999-44047 note |
Jet Sub-assy, Slow
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21206 — Strainer Sub-assy | ||||
| 21294-33080 |
Strainer Sub-assy
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21811-11060 note |
Strainer Sub-assy
1974-01 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21811-30010 note |
Strainer Sub-assy
1974-01 → 1977-07
ended
|
T,2T TA1# | — | |
| 90401-13013 |
Strainer Sub-assy
1972-10 → 1974-01
ended
|
T,2T TA1# | — | |
| 21209 — Float Sub-assy | ||||
| 21209-33010 |
Float Sub-assy
1970-12 → 1971-02
ended
|
T,2T TA1# | — | |
| 21209-33011 |
Float Sub-assy
1971-02 → 1972-07
ended
|
T,2T TA1# | — | |
| 21209-33080 |
Float Sub-assy
1972-08 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21211 — Venturi, 1ST Small | ||||
| 21211-25010 |
Venturi, 1ST Small
1970-12 → 1972-01
ended
|
T TA10 | — | |
| 21211-25011 |
Venturi, 1ST Small
1972-01 → 1973-04
ended
|
T TA10 | — | |
| 21211-25012 |
Venturi, 1ST Small
1973-04 → 1975-09
ended
|
T TA10 | — | |
| 21211-25180 |
Venturi, 1ST Small
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21211-26010 |
Venturi, 1ST Small
1970-12 → 1972-02
ended
|
2T TA12 | — | |
| 21211-26011 |
Venturi, 1ST Small
1973-04 → 1975-09
ended
|
2T TA12 | — | |
| 21211-26030 |
Venturi, 1ST Small
1972-02 → 1973-04
ended
|
2T TA12 | — | |
| 21211-26041 |
Venturi, 1ST Small
1972-08 → 1973-04
ended
|
2TB TA12 | — | |
| 21211-26042 |
Venturi, 1ST Small
1973-04 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21212 — Venturi, 2ND Small | ||||
| 21212-25010 |
Venturi, 2ND Small
1970-12 → 1975-09
ended
|
T TA10 | — | |
| 21212-25180 |
Venturi, 2ND Small
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21212-26010 |
Venturi, 2ND Small
1970-12 → 1975-09
ended
|
2T TA12 | — | |
| 21212-26040 |
Venturi, 2ND Small
1972-08 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21251 — Jet, 1ST Main | ||||
| 21251-25010 note |
Jet, 1ST Main
1970-12 → 1974-01
ended
|
T TA10 | — | |
| 21251-26010 note |
Jet, 1ST Main
1970-12 → 1973-04
ended
|
2T TA12 | — | |
| 21251-41084 note |
Jet, 1ST Main
1972-08 → 1973-04
ended
|
2TB TA12 | — | |
| 90999-41080 note |
Jet, 1ST Main
1973-04 → 1977-07
ended
|
2TB TA12,14 | — | |
| 90999-41102 note |
Jet, 1ST Main
1974-01 → 1975-09
ended
|
T TA10 | — | |
| 90999-41105 note |
Jet, 1ST Main
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 90999-41106 note |
Jet, 1ST Main
1973-04 → 1975-09
ended
|
2T TA12 | — | |
| 21253 — Jet, 2ND Main | ||||
| 21253-31085 note |
Jet, 2ND Main
1970-12 → 1972-01
ended
|
2T TA12 | — | |
| 21253-31094 note |
Jet, 2ND Main
1970-12 → 1972-01
ended
|
T TA10 | — | |
| 90999-42132 note |
Jet, 2ND Main
1972-08 → 1977-07
ended
|
2TB TA12,14 | — | |
| 90999-42147 note |
Jet, 2ND Main
1972-01 → 1975-09
ended
|
T TA10 | — | |
| 90999-42150 note |
Jet, 2ND Main
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 90999-42162 note |
Jet, 2ND Main
1972-01 → 1975-09
ended
|
2T TA12 | — | |
| 21255 — Jet, Power | ||||
| 21255-25010 note |
Jet, Power
1970-12 → 1971-05
ended
|
T,2T TA1# | — | |
| 21255-26040 note |
Jet, Power
1972-08 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21255-41081 note |
Jet, Power
1971-05 → 1975-09
ended
|
T,2T TA1# | — | |
| 90999-43060 note |
Jet, Power
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21291 — Glass, Level Gage | ||||
| 21291-33010 |
Glass, Level Gage
1970-12 → 1973-11
ended
|
T,2T# TA1# | — | |
| 21291-60200 |
Glass, Level Gage
1973-11 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21301 — Valve Sub-assy, Needle | ||||
| 21301-26350 |
Valve Sub-assy, Needle
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21301-33010 |
Valve Sub-assy, Needle
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21301-33081 |
Valve Sub-assy, Needle
1972-08 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21301-33081 |
Valve Sub-assy, Needle
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21313 — Ball, Steel, NO.1(FOR DISCHARGE WEIGHT) | ||||
| 21313-11020 |
Ball, Steel, NO.1(FOR DISCHARGE WEIGHT)
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21314 — Ball, Steel, NO.2(FOR PUMP PLUNGER) | ||||
| 21314-11020 |
Ball, Steel, NO.2(FOR PUMP PLUNGER)
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21314-60010 |
Ball, Steel, NO.2(FOR PUMP PLUNGER)
1970-12 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21314-60010 |
Ball, Steel, NO.2(FOR PUMP PLUNGER)
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21341 — Valve, Power | ||||
| 21304-30010 |
Valve, Power
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21351 — Piston, Power | ||||
| 21351-33080 |
Piston, Power
1972-08 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21708-22010 |
Piston, Power
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21353 — Plunger, Pump | ||||
| 21353-33010 |
Plunger, Pump
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21511 — Clamp, Level Gage | ||||
| 21511-33010 |
Clamp, Level Gage
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21531 — Retainer, Coil Housing | ||||
| 21531-26350 |
Retainer, Coil Housing
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21531-30010 |
Retainer, Coil Housing
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21536 — Plate, Coil Housing | ||||
| 21536-25180 |
Plate, Coil Housing
1975-10 → 1977-07
ended
|
2T# TA14 | — | |
| 21536-34080 |
Plate, Coil Housing
1972-08 → 1973-04
ended
|
T,2T TA1# | — | |
| 21536-40010 |
Plate, Coil Housing
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21536-44100 |
Plate, Coil Housing
1973-04 → 1975-09
ended
|
T,2T TA1# | — | |
| 21538 — Retainer, Ball Check | ||||
| 21538-31010 |
Retainer, Ball Check
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21561 — Weight, Pump Discharge | ||||
| 21561-22010 |
Weight, Pump Discharge
1973-04 → 1975-09
ended
|
2T# TA12 | — | |
| 21561-22010 |
Weight, Pump Discharge
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21561-25010 |
Weight, Pump Discharge
1970-12 → 1975-09
ended
|
T TA10 | — | |
| 21561-30010 |
Weight, Pump Discharge
1970-12 → 1973-04
ended
|
2T# TA12 | — | |
| 21572 — Stop, Power Piston | ||||
| 21572-33080 |
Stop, Power Piston
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21575 — Stopper, B(FOR DISCHARGE WEIGHT) | ||||
| 21574-26220 |
Stopper, B(FOR DISCHARGE WEIGHT)
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21575-25010 |
Stopper, B(FOR DISCHARGE WEIGHT)
1970-12 → 1975-09
ended
|
T TA10 | — | |
| 21575-33011 |
Stopper, B(FOR DISCHARGE WEIGHT)
1970-12 → 1975-09
ended
|
2T# TA12 | — | |
| 21611 — Gasket, Main Jet | ||||
| 21611-22010 |
Gasket, Main Jet
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21614 — Gasket, Venturi | ||||
| 21614-33010 note |
Gasket, Venturi
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21614-33080 note |
Gasket, Venturi
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21617 — Gasket, Main Passage Plug | ||||
| 21617-30010 |
Gasket, Main Passage Plug
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21618 — Gasket, Needle Valve Seat | ||||
| 21618-24030 |
Gasket, Needle Valve Seat
1972-08 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21618-60010 |
Gasket, Needle Valve Seat
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21621 — Gasket, Union Nipple | ||||
| 21619-22010 note |
Gasket, Union Nipple
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21621-30010 note |
Gasket, Union Nipple
1972-08 → 1972-10
ended
|
T,2T TA1# | — | |
| 21621-30010 note |
Gasket, Union Nipple
1974-01 → 1977-07
ended
|
T,2T TA1# | — | |
| 21633-24030 note |
Gasket, Union Nipple
1972-08 → 1977-07
ended
|
T,2T# TA1# | — | |
| 90430-13195 note |
Gasket, Union Nipple
1972-10 → 1974-01
ended
|
T,2T TA1# | — | |
| 21622 — Gasket, Air Horn | ||||
| 21622-26350 |
Gasket, Air Horn
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21622-33080 |
Gasket, Air Horn
1970-12 → 1971-08
ended
|
T,2T TA1# | — | |
| 21622-33081 |
Gasket, Air Horn
1971-09 → 1972-07
ended
|
T,2T TA1# | — | |
| 21622-33082 |
Gasket, Air Horn
1972-08 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21622-33082 |
Gasket, Air Horn
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21625 — Gasket, Level Gage | ||||
| 21641-33040 |
Gasket, Level Gage
1970-12 → 1973-11
ended
|
T,2T# TA1# | — | |
| 21655-60200 |
Gasket, Level Gage
1973-11 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21626 — Gasket, Case | ||||
| 21649-33080 |
Gasket, Case
1970-12 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21627 — Gasket, Coil Housing | ||||
| 21627-34080 |
Gasket, Coil Housing
1972-08 → 1977-07
ended
|
T,2T TA1# | — | |
| 21627-50010 |
Gasket, Coil Housing
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 21649 — Gasket(FOR PUMP DISCHARGE WEIGHT STOPPER) | ||||
| 21641-33011 |
Gasket(FOR PUMP DISCHARGE WEIGHT STOPPER)
1970-12 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21641-33011 |
Gasket(FOR PUMP DISCHARGE WEIGHT STOPPER)
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21655-11040 |
Gasket(FOR PUMP DISCHARGE WEIGHT STOPPER)
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21699 — Boot(FOR PUMP PLUNGER) | ||||
| 21699-21061 |
Boot(FOR PUMP PLUNGER)
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21722 — Spring, Pump Damping | ||||
| 21722-22010 |
Spring, Pump Damping
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21734 — Spring, Power Piston | ||||
| 21734-22050 |
Spring, Power Piston
1970-12 → 1972-02
ended
|
2T TA12 | — | |
| 21734-33080 |
Spring, Power Piston
1970-12 → 1974-01
ended
|
T TA10 | — | |
| 21734-33080 |
Spring, Power Piston
1972-02 → 1974-01
ended
|
2T TA12 | — | |
| 21734-33080 |
Spring, Power Piston
1974-01 → 1977-07
ended
|
T,2T TA1# | — | |
| 21734-33081 |
Spring, Power Piston
1972-08 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21751 — Union, Nipple | ||||
| 21751-33080 note |
Union, Nipple
1972-08 → 1974-01
ended
|
T,2T# TA1# | — | |
| 21754-25011 note |
Union, Nipple
1970-12 → 1971-03
ended
|
2T TA12 | — | |
| 21754-25012 note |
Union, Nipple
1970-12 → 1971-03
ended
|
T TA10 | — | |
| 21754-25013 note |
Union, Nipple
1971-03 → 1972-07
ended
|
T TA10 | — | |
| 21754-25014 note |
Union, Nipple
1972-08 → 1972-10
ended
|
T,2T TA1# | — | |
| 21754-26010 note |
Union, Nipple
1971-03 → 1972-07
ended
|
2T TA12 | — | |
| 21894-25010 note |
Union, Nipple
1972-10 → 1974-01
ended
|
T,2T TA1# | — | |
| 21894-25020 note |
Union, Nipple
1974-01 → 1975-09
ended
|
T,2T TA1# | — | |
| 21894-26400 note |
Union, Nipple
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 90404-13105 note |
Union, Nipple
1970-12 → 1972-07
ended
|
T,2T TA1# | — | |
| 90405-06167 note |
Union, Nipple
1974-01 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21763 — Pin, Float Lever | ||||
| 21763-26350 |
Pin, Float Lever
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21763-29270 |
Pin, Float Lever
1970-12 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21763-29270 |
Pin, Float Lever
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21781 — Plug, Main Passage(FOR CARBURETOR JET) | ||||
| 21781-30020 |
Plug, Main Passage(FOR CARBURETOR JET)
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21827 — Screw, Connector Set | ||||
| 21827-33010 |
Screw, Connector Set
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21831 — Screw, Power Piston Stop | ||||
| 21842-33010 |
Screw, Power Piston Stop
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21836 — Screw, Thermostat Case Set | ||||
| 21832-38010 |
Screw, Thermostat Case Set
1975-10 → 1977-07
ended
|
2T# TA14 | — | |
| 21832-44010 |
Screw, Thermostat Case Set
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21837 — Screw, Coil Housing Set | ||||
| 21821-25010 |
Screw, Coil Housing Set
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21842-33010 |
Screw, Coil Housing Set
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21842 — Screw, Set(FOR CARBURETOR LEVEL GAGE CLAMP SET) | ||||
| 21842-33010 |
Screw, Set(FOR CARBURETOR LEVEL GAGE CLAMP SET)
1970-12 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21884 — Washer, Thermostat Case Set | ||||
| 21885-44010 |
Washer, Thermostat Case Set
1970-12 → 1975-09
ended
|
T,2T TA1# | — | |
| 21934 — Solenoid, Throttle Valve | ||||
| 21062-25010 note |
Solenoid, Throttle Valve
1973-04 → 1975-09
ended
|
T,2T# TA1# | — | |
| 21062-25010 note |
Solenoid, Throttle Valve
1975-10 → 1977-07
ended
|
2TB TA14 | — | |
| 21062-25180 |
Solenoid, Throttle Valve
1975-10 → 1977-07
ended
|
2T TA14 | — | |
| 21062-26050 note |
Solenoid, Throttle Valve
1973-04 → 1977-07
ended
|
2TB TA12,14 | — | |
| 21934E — Ring, O(FOR SOLENOID VALVE) | ||||
| 21655-44101 |
Ring, O(FOR SOLENOID VALVE)
1973-04 → 1977-07
ended
|
T,2T# TA1# | — | |
| 21934F — Gasket | ||||
| 21617-10010 |
Gasket
1973-04 → 1977-07
ended
|
T,2T# TA1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
