Toyota Carina

1977-08 → 1981-07 · chassis TA4#(A) · catalogue 221220 · Europe

Discontinued model Data version 1982-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

17 part groups · 2 illustrations

Illustrations

Figure MB7305E MB7305E 1977-08 → — Figure MB7307E MB7307E 1977-08 → —

Part groups

PNCDescription
63310 Headlining Assy, Roof
63317 Pad, Roof Headlining Rear Garnish
63341 Pad, Roof Silencer, NO.1
63342 Pad, Roof Silencer, NO.2
63343 Pad, Roof Silencer, NO.3
63347 Pad, Roof Side Vent Silencer
63361 Support, Roof Headlining, NO.1
63362 Support, Roof Headlining, NO.2
63363 Support, Roof Headlining, NO.3
63364 Support, Roof Headlining, NO.4
63365 Support, Roof Headlining, NO.5
63372 Retainer, Headlining Support
63381 Retainer, Headlining, Front
63391 Trim, Roof Headlining, Front
63392 Trim, Roof Headlining, Rear
63393 Trim, Roof Headlining, Center
63398 Plate, Roof Headlining Support
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
