Toyota Prius

2015-11 → 2022-11 · chassis ZVW5# · catalogue 222540 · Europe

Supported model Data version 2023-11

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Radiator Grille

4 part groups · 2 illustrations

Illustrations

Figure 534770A

534770A 2015-11 → 2018-12

Figure 535815C

535815C 2018-12 → —

Part groups

PNC	Description
52161R	Piece, Front Bumper
53101	Grille Sub-assy, Radiator
53111	Grille, Radiator
53115B	Bracket, Radiator Grille

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
