Toyota Prius(PLUG-IN HBD)
2009-12 → 2010-10 · chassis ZVW35 · catalogue 224510 · Europe
Supported model
Data version 2011-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 55843A — Duct, Heater TO Register, NO.1 | ||||
| 55843-47050 |
Duct, Heater TO Register, NO.1
2009-12 → —
|
ZVW35 RHD | — | |
| 55843-47060 |
Duct, Heater TO Register, NO.1
2009-12 → —
|
ZVW35 LHD | — | |
| 55844 — Duct, Heater TO Register, NO.2 | ||||
| 55844-47050 |
Duct, Heater TO Register, NO.2
2009-12 → —
|
ZVW35 RHD | — | |
| 55844-47060 |
Duct, Heater TO Register, NO.2
2009-12 → —
|
ZVW35 LHD | — | |
| 55845A — Duct, Heater TO Register, NO.3 | ||||
| 55845-47030 |
Duct, Heater TO Register, NO.3
2009-12 → —
|
ZVW35 RHD | — | |
| 55845-47040 |
Duct, Heater TO Register, NO.3
2009-12 → —
|
ZVW35 LHD | — | |
| 55950G — Nozzle Assy, Defroster | ||||
| 55950-47030 |
Nozzle Assy, Defroster
2009-12 → —
|
ZVW35 RHD | — | |
| 55950-47040 |
Nozzle Assy, Defroster
2009-12 → —
|
ZVW35 LHD | — | |
| 55973 — Duct, Side Defroster Nozzle, NO.3 | ||||
| 55973-47010 |
Duct, Side Defroster Nozzle, NO.3
2009-12 → —
|
ZVW35 RHD | — | |
| 55973-47020 |
Duct, Side Defroster Nozzle, NO.3
2009-12 → —
|
ZVW35 LHD | — | |
| 55990B — Nozzle Assy, Defroster, Lower | ||||
| 55990-47050 |
Nozzle Assy, Defroster, Lower
2009-12 → —
|
ZVW35 RHD | — | |
| 55990-47060 |
Nozzle Assy, Defroster, Lower
2009-12 → —
|
ZVW35 LHD | — | |
| 87201 — Duct Sub-assy, Air, NO.1 | ||||
| 87211-47130 |
Duct Sub-assy, Air, NO.1
2009-12 → —
|
ZVW35 RHD | — | |
| 87211-47150 |
Duct Sub-assy, Air, NO.1
2009-12 → —
|
ZVW35 LHD | — | |
| 87201B — Duct Sub-assy, Air, NO.2 | ||||
| 87211-47140 |
Duct Sub-assy, Air, NO.2
2009-12 → —
|
ZVW35 RHD | — | |
| 87211-47160 |
Duct Sub-assy, Air, NO.2
2009-12 → —
|
ZVW35 LHD | — | |
| 87201F — Duct Sub-assy, Air, NO.3 | ||||
| 87220-47010 |
Duct Sub-assy, Air, NO.3
2009-12 → —
|
ZVW35 RHD | — | |
| 87220-47020 |
Duct Sub-assy, Air, NO.3
2009-12 → —
|
ZVW35 LHD | — | |
| 87212 — Duct, Air, Rear NO.1 | ||||
| 87215-12050 |
Duct, Air, Rear NO.1
2009-12 → —
|
ZVW35 | — | |
| 87212F — Duct, Air, Rear NO.2 | ||||
| 87213-12090 |
Duct, Air, Rear NO.2
2009-12 → —
|
ZVW35 | — | |
| 87212G — Duct, Air, Rear NO.3 | ||||
| 87276-47010 |
Duct, Air, Rear NO.3
2009-12 → —
|
ZVW35 | — | |
| 87212H — Duct, Air, Rear NO.4 | ||||
| 87202-47030 |
Duct, Air, Rear NO.4
2009-12 → —
|
ZVW35 | — | |
| 87212J — Duct, Air, Rear NO.5 | ||||
| 87275-47010 |
Duct, Air, Rear NO.5
2009-12 → —
|
ZVW35 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
