Toyota Prius(PLUG-IN HBD)
2009-12 → 2010-10 · chassis ZVW35 · catalogue 224510 · Europe
Supported model
Data version 2011-05
Armrest & Visor
21 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 74221 | Cover, Door Armrest, RH |
| 74222 | Cover, Door Armrest, LH |
| 74230A | Panel Assy, Front Door Armrest Base, RH |
| 74240A | Panel Assy, Front Door Armrest Base, LH |
| 74261 | Cover, Rear Door Armrest, RH |
| 74262 | Cover, Rear Door Armrest, LH |
| 74270 | Panel Assy, Rear Door Armrest Base, RH |
| 74280 | Panel Assy, Rear Door Armrest Base, LH |
| 74310 | Visor Assy, RH |
| 74317 | Cover, Visor Bracket, RH |
| 74318 | Cover, Visor Bracket, LH |
| 74320 | Visor Assy, LH |
| 74336 | Clip, Visor Arm Set |
| 74348 | Holder, Visor |
| 74610S | Grip Assy, Assist |
| 74611C | Cover, Assist Grip, LH |
| 74612 | Cover, Assist Grip |
| 74612C | Cover, Assist Grip, RH |
| 74620B | Grip Assy, Assist, Rear |
| 74645A | Cover, Door Assist Grip, RH |
| 74646 | Cover, Door Assist Grip, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
