Toyota Prius(PLUG-IN HBD)
2012-05 → 2016-04 · chassis ZVW35 · catalogue 224520 · Europe
Supported model
Data version 2016-10
Meter
27 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 83132 | Case, Combination Meter |
| 83132B | Case, Combination Meter NO.3 |
| 83132D | Case, Combination Meter, NO.2 |
| 83134B | Cover, Combination Meter, NO.2 |
| 83134D | Cover, Combination Meter, NO.3 |
| 83134E | Cover, Combination Meter, NO.4 |
| 83141A | Computer, Combination Meter Mirror |
| 83142A | Wire, Combination Meter |
| 83143A | Wire, Combination Meter Mirror, NO.2 |
| 83144A | Mirror, Combination Meter |
| 83145 | Lens, Meter, NO.1 |
| 83145A | Lens, Meter, NO.2 |
| 83145B | Lens, Meter, NO.3 |
| 83161 | Case, Combination Meter Mirror, NO.1 |
| 83162 | Case, Combination Meter Mirror, NO.2 |
| 83163 | Plate, Combination Meter Mirror, NO.1 |
| 83164 | Plate, Combination Meter Mirror, NO.2 |
| 83165 | Mirror, Combination Meter, NO.2 |
| 83167 | Glass, Combination Meter Mirror |
| 83168 | Display, Combination |
| 83247 | Plate, Meter Circuit |
| 83247B | Plate, Meter Circuit, NO.2 |
| 83247C | Plate, Mater Circuit, NO.3 |
| 83247E | Plate, Mater Circuit, NO.4 |
| 83247H | Plate, Meter Circuit, NO.5 |
| 83821A | Cover, Combination Meter, NO.1 |
| 83857 | Reflector, Combination Meter, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
