Toyota Prius Phv
2016-09 → 2022-11 · chassis ZVW52 · catalogue 224530 · Europe
Supported model
Data version 2023-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 69065A — Cylinder Sub-assy, Airbag Cut Off Switch | ||||
| 69065-12460 |
Cylinder Sub-assy, Airbag Cut Off Switch
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 69065-12460 |
Cylinder Sub-assy, Airbag Cut Off Switch
2019-05 → —
|
ZVW52 | — | |
| 82210N — Instrument Panel Fusible Link | ||||
| 90982-08306 note |
Instrument Panel Fusible Link
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-08306 note |
Instrument Panel Fusible Link
2019-05 → —
|
ZVW52 | — | |
| 82600D — Instrument Panel Fuse | ||||
| 90982-09019 note |
Instrument Panel Fuse
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-09020 note |
Instrument Panel Fuse
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-09021 note |
Instrument Panel Fuse
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-09022 note |
Instrument Panel Fuse
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-09023 note |
Instrument Panel Fuse
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90982-09019 note |
Instrument Panel Fuse
2019-05 → —
|
ZVW52 | — | |
| 90982-09020 note |
Instrument Panel Fuse
2019-05 → —
|
ZVW52 | — | |
| 90982-09021 note |
Instrument Panel Fuse
2019-05 → —
|
ZVW52 | — | |
| 90982-09022 note |
Instrument Panel Fuse
2019-05 → —
|
ZVW52 | — | |
| 90982-09023 note |
Instrument Panel Fuse
2019-05 → —
|
ZVW52 | — | |
| 82660F — Block Assy, Relay | ||||
| 82660-47050 |
Block Assy, Relay
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 82660-47060 |
Block Assy, Relay
2016-09 → 2019-04
ended
|
ZVW52 RHD | — | |
| 82660-47050 |
Block Assy, Relay
2019-05 → —
|
ZVW52 LHD | — | |
| 82660-47060 |
Block Assy, Relay
2019-05 → —
|
ZVW52 RHD | — | |
| 82672A — Cover, Junction Block | ||||
| 82672-47150 |
Cover, Junction Block
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 82672-47170 |
Cover, Junction Block
2019-05 → —
|
ZVW52 | — | |
| 82673A — Bracket, Junction Block, NO.1 | ||||
| 82673-47110 |
Bracket, Junction Block, NO.1
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 82673-47190 |
Bracket, Junction Block, NO.1
2016-09 → 2019-04
ended
|
ZVW52 RHD | — | |
| 82673-47110 |
Bracket, Junction Block, NO.1
2019-05 → —
|
ZVW52 LHD | — | |
| 82673-47190 |
Bracket, Junction Block, NO.1
2019-05 → —
|
ZVW52 RHD | — | |
| 82673B — Bracket, Junction Block, NO.2 | ||||
| 82673-47200 |
Bracket, Junction Block, NO.2
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 82673-47210 |
Bracket, Junction Block, NO.2
2016-09 → 2019-04
ended
|
ZVW52 RHD | — | |
| 82673-47200 |
Bracket, Junction Block, NO.2
2019-05 → —
|
ZVW52 LHD | — | |
| 82673-47210 |
Bracket, Junction Block, NO.2
2019-05 → —
|
ZVW52 RHD | — | |
| 82715 — Bracket,Wiring Harness Clamp | ||||
| 82715-47700 |
Bracket,Wiring Harness Clamp
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 82715-47700 |
Bracket,Wiring Harness Clamp
2019-05 → —
|
ZVW52 LHD | — | |
| 82730 — Block Assy, Instrument Panel Junction | ||||
| 82730-47530 |
Block Assy, Instrument Panel Junction
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 82730-47560 |
Block Assy, Instrument Panel Junction
2019-05 → —
|
ZVW52 | — | |
| 82877 — Box, Computer Integration, RH | ||||
| 82877-47040 |
Box, Computer Integration, RH
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 82877-47040 |
Box, Computer Integration, RH
2019-05 → —
|
ZVW52 LHD | — | |
| 84340 — Switch Assy, Stop Lamp | ||||
| 84340-49075 |
Switch Assy, Stop Lamp
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 84340-19085 |
Switch Assy, Stop Lamp
2019-05 → 2020-06
ended
|
ZVW52 | — | |
| 84340-19095 |
Switch Assy, Stop Lamp
2020-07 → —
|
ZVW52 | — | |
| 84345 — Adjuster, Stop Lamp Switch Mounting | ||||
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2019-05 → —
|
ZVW52 | — | |
| 84550 — Switch Assy, Parking Brake | ||||
| 84550-30080 |
Switch Assy, Parking Brake
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 84550-30080 |
Switch Assy, Parking Brake
2019-05 → —
|
ZVW52 | — | |
| 85530A — Relay, Power Outlet Socket | ||||
| 90987-02027 |
Relay, Power Outlet Socket
2020-07 → —
|
ZVW52 | — | |
| 85916D — Relay, Fog Lamp | ||||
| 90987-02027 |
Relay, Fog Lamp
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 90987-02027 |
Relay, Fog Lamp
2019-05 → —
|
ZVW52 | — | |
| 85940 — Relay Assy, Windshield Wiper | ||||
| 85940-47060 |
Relay Assy, Windshield Wiper
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 85940-47060 |
Relay Assy, Windshield Wiper
2019-05 → —
|
ZVW52 | — | |
| 85940-47060 note |
Relay Assy, Windshield Wiper
2019-05 → 2023-03
ended
|
ZVW52 LHD | — | |
| 87989 — Relay, Mirror Control | ||||
| 85927-22010 |
Relay, Mirror Control
2016-09 → 2018-10
ended
|
ZVW52 | — | |
| 90987-04004 |
Relay, Mirror Control
2018-11 → 2019-04
ended
|
ZVW52 | — | |
| 90987-04004 |
Relay, Mirror Control
2019-05 → —
|
ZVW52 | — | |
| 88150A — Computer Assy, Driving Support | ||||
| 88150-47140 |
Computer Assy, Driving Support
2016-09 → 2018-01
ended
|
ZVW52 | — | |
| 88150-47140 note |
Computer Assy, Driving Support
2016-09 → 2018-01
ended
|
ZVW52 RHD | — | |
| 88150-47140 note |
Computer Assy, Driving Support
2016-09 → 2018-01
ended
|
ZVW52 LHD | — | |
| 88150-47140 note |
Computer Assy, Driving Support
2016-09 → 2018-01
ended
|
ZVW52 | — | |
| 88150-47160 |
Computer Assy, Driving Support
2018-01 → 2019-04
ended
|
ZVW52 | — | |
| 88150-47160 note |
Computer Assy, Driving Support
2018-01 → 2019-04
ended
|
ZVW52 RHD | — | |
| 88150-47160 note |
Computer Assy, Driving Support
2018-01 → 2019-04
ended
|
ZVW52 LHD | — | |
| 88150-47160 note |
Computer Assy, Driving Support
2018-01 → 2019-04
ended
|
ZVW52 | — | |
| 88150-47190 |
Computer Assy, Driving Support
2019-05 → 2020-07
ended
|
ZVW52 | — | |
| 886A0 — Computer Assy, Heat Pump | ||||
| 886A0-47010 note |
Computer Assy, Heat Pump
2016-09 → 2017-12
ended
|
ZVW52 | — | |
| 886A0-47020 note |
Computer Assy, Heat Pump
2017-12 → 2019-04
ended
|
ZVW52 | — | |
| 886A0-47030 |
Computer Assy, Heat Pump
2019-05 → —
|
ZVW52 | — | |
| 89111 — Computer, Network Gateway | ||||
| 89111-47070 |
Computer, Network Gateway
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 89111-33090 |
Computer, Network Gateway
2019-05 → 2020-07
ended
|
ZVW52 | — | |
| 89111-47090 |
Computer, Network Gateway
2020-07 → —
|
ZVW52 | — | |
| 89120A — Sensor, Automatic Light Control | ||||
| 89121-30020 |
Sensor, Automatic Light Control
2016-09 → 2019-04
ended
|
ZVW52 | — | |
| 89121-30020 |
Sensor, Automatic Light Control
2019-05 → —
|
ZVW52 | — | |
| 89221 — Computer, Multiplex Network Body | ||||
| 89220-4EN00 note |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 89220-4EN10 note |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 89220-4EN20 |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 89220-4EN30 note |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 LHD | — | |
| 89220-4EN40 note |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 RHD | — | |
| 89220-4EN50 |
Computer, Multiplex Network Body
2016-09 → 2019-04
ended
|
ZVW52 RHD | — | |
| 89220-4EX10 note |
Computer, Multiplex Network Body
2019-05 → 2021-06
ended
|
ZVW52 LHD | — | |
| 89220-4EX20 note |
Computer, Multiplex Network Body
2019-05 → 2021-06
ended
|
ZVW52 LHD | — | |
| 89220-4EX30 |
Computer, Multiplex Network Body
2019-05 → 2021-06
ended
|
ZVW52 LHD | — | |
| 89220-4EX40 note |
Computer, Multiplex Network Body
2019-05 → 2020-07
ended
|
ZVW52 LHD | — | |
| 89220-4EX40 note |
Computer, Multiplex Network Body
2020-07 → 2021-06
ended
|
ZVW52 LHD | — | |
| 89220-4EX50 note |
Computer, Multiplex Network Body
2019-05 → 2021-06
ended
|
ZVW52 RHD | — | |
| 89220-4EX60 |
Computer, Multiplex Network Body
2019-05 → 2021-06
ended
|
ZVW52 RHD | — | |
| 89220-4F520 note |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 LHD | — | |
| 89220-4F530 note |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 LHD | — | |
| 89220-4F540 |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 LHD | — | |
| 89220-4F550 note |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 LHD | — | |
| 89220-4F560 note |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 RHD | — | |
| 89220-4F570 |
Computer, Multiplex Network Body
2021-06 → —
|
ZVW52 RHD | — | |
| 89650 — Computer Assy, Power Steering | ||||
| 89650-47640 |
Computer Assy, Power Steering
2016-09 → 2018-12
ended
|
ZVW52 | — | |
| 89650-47760 note |
Computer Assy, Power Steering
2018-12 → 2019-04
ended
|
ZVW52 | — | |
| 89650-47760 note |
Computer Assy, Power Steering
2019-05 → 2020-07
ended
|
ZVW52 | — | |
| 89650-47770 note |
Computer Assy, Power Steering
2019-05 → 2020-07
ended
|
ZVW52 | — | |
| 89650-47800 note |
Computer Assy, Power Steering
2020-07 → —
|
ZVW52 | — | |
| 89650-47810 note |
Computer Assy, Power Steering
2020-07 → —
|
ZVW52 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
