Toyota Prius Phv

2016-09 → 2022-11 · chassis ZVW52 · catalogue 224530 · Europe

Supported model Data version 2023-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

15 part groups · 2 illustrations

Illustrations

Figure 744410D 744410D 2016-09 → — Figure 744411A 744411A 2016-09 → —

Part groups

PNCDescription
11285A Label, Coolant System Notice
11293D Label, Engine Caution
16793B Label, Cooling Fan Information
42661 Label, Tire Pressure Information
47997C Label, Accumulator Caution, NO.1
69339C Label, Child Protector Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515C Label, Theft Warning Information
74559B Label, Fuel Information
74573D Label, Electric Vehicle Battery Caution
74596A Label, Side Airbag Caution
861C8 Label, Mobile Wireless Charger Caution
88723E Label, Cooler Service Caution
89356A Label, Clearance Warning Information
G9275 Label, Battery Caution, NO.1
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
