Toyota Prius +/V/A(ALPHA)

2012-03 → 2021-09 · chassis ZVW40 · catalogue 225510 · Europe

Supported model Data version 2017-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Panel & Glass

25 part groups · 2 illustrations

Illustrations

Figure 676780G 676780G 2012-03 → — Figure 676781A 676781A 2012-03 → —

Part groups

PNCDescription
64818C Spacer, Back Window Glass, NO.1
64819 Spacer, Back Window Glass, NO.2
64885A Channel, Back Window Glass, RH
64886 Channel, Back Window Glass, LH
67005 Panel Sub-assy, Back Door
67005B Cushion(FOR BACK DOOR PANEL)
67372A Weight, Back Door
67395 Protector, Back Door, Lower
67750 Board Assy, Back Door Trim
67750A Clip(FOR BACK DOOR TRIM)
67754A Cover, Back Door Hole
67837N Seal, Back Door Dust Proof
67847 Cover, Back Door Service Hole, RH
67848 Cover, Back Door Service Hole, LH
67881A Weatherstrip, Back Door
67937B Garnish, Back Door Side, RH
67937C Clip(FOR BACK DOOR SIDE GARNISH)
67938A Garnish, Back Door Side, LH
67939B Garnish, Back Door, Center
67939C Clip(FOR BACK DOOR CENTER GARNISH)
68131 Glass, Back Door
68294A Dam, Back Door Glass Adhesive
75573G Moulding, Back Window, Outside RH NO.1
75574C Moulding, Back Window, Outside LH NO.1
75575D Moulding, Back Window, Lower
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
