Toyota Prius +/V/A(ALPHA)

2012-03 → 2021-09 · chassis ZVW40 · catalogue 225510 · Europe

Supported model Data version 2017-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

17 part groups · 2 illustrations

Illustrations

Figure 743408 743408 2012-03 → — Figure 743407C 743407C 2012-03 → —

Part groups

PNCDescription
74221 Cover, Door Armrest, RH
74222 Cover, Door Armrest, LH
74230A Panel Assy, Front Door Armrest Base, RH
74240A Panel Assy, Front Door Armrest Base, LH
74261 Cover, Rear Door Armrest, RH
74262 Cover, Rear Door Armrest, LH
74270 Panel Assy, Rear Door Armrest Base, RH
74280 Panel Assy, Rear Door Armrest Base, LH
74310 Visor Assy, RH
74320 Visor Assy, LH
74348 Holder, Visor
74610S Grip Assy, Assist
74612 Cover, Assist Grip
74620B Grip Assy, Assist, Rear
74635A Clip
74811B Handle, Door Pull
74813C Clip
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
