Toyota Lexus IS250/350/2##D
2005-08 → 2013-04 · chassis ALE20,GSE2# · catalogue 242520 · Europe
Supported model
Data version 2013-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 13050 — Gear Assy, Camshaft Timing | ||||
| 13050-31040 |
Gear Assy, Camshaft Timing
2005-08 → 2006-11
ended
|
4GRFSE GSE20 | — | |
| 13050-31041 |
Gear Assy, Camshaft Timing
2006-11 → 2007-01
ended
|
4GRFSE GSE20 | — | |
| 13050-31120 |
Gear Assy, Camshaft Timing
2007-01 → 2008-04
ended
|
4GRFSE GSE20 | — | |
| 13050-31121 |
Gear Assy, Camshaft Timing
2008-04 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13050-31121 |
Gear Assy, Camshaft Timing
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13050-31121 |
Gear Assy, Camshaft Timing
2010-08 → 2012-07
ended
|
4GRFSE GSE20 | — | |
| 13050-31122 |
Gear Assy, Camshaft Timing
2012-07 → —
|
4GRFSE GSE20 | — | |
| 13050-31162 |
Gear Assy, Camshaft Timing
2010-08 → 2011-04
ended
|
2GRFSE GSE21 | — | |
| 13050-31163 |
Gear Assy, Camshaft Timing
2011-04 → —
|
2GRFSE GSE21 | — | |
| 13053 — Camshaft Sub-assy, NO.3 | ||||
| 13053-31021 |
Camshaft Sub-assy, NO.3
2005-08 → 2008-05
ended
|
4GRFSE GSE20 | — | |
| 13053-31022 |
Camshaft Sub-assy, NO.3
2008-05 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13053-31022 |
Camshaft Sub-assy, NO.3
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13053-31022 |
Camshaft Sub-assy, NO.3
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13053-31051 |
Camshaft Sub-assy, NO.3
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13054 — Camshaft Sub-assy, NO.4 | ||||
| 13054-31021 |
Camshaft Sub-assy, NO.4
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13054-31021 |
Camshaft Sub-assy, NO.4
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13054-31021 |
Camshaft Sub-assy, NO.4
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13054-31050 |
Camshaft Sub-assy, NO.4
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13070 — Gear Assy, Camshaft Timing Exhaust, RH | ||||
| 13070-31020 |
Gear Assy, Camshaft Timing Exhaust, RH
2005-08 → 2006-03
ended
|
4GRFSE GSE20 | — | |
| 13070-31040 |
Gear Assy, Camshaft Timing Exhaust, RH
2006-03 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13070-31040 |
Gear Assy, Camshaft Timing Exhaust, RH
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13070-31040 |
Gear Assy, Camshaft Timing Exhaust, RH
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13070-31050 |
Gear Assy, Camshaft Timing Exhaust, RH
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13080 — Gear Assy, Camshaft Timing Exhaust, LH | ||||
| 13080-31020 |
Gear Assy, Camshaft Timing Exhaust, LH
2005-08 → 2006-03
ended
|
4GRFSE GSE20 | — | |
| 13080-31030 |
Gear Assy, Camshaft Timing Exhaust, LH
2006-03 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13080-31030 |
Gear Assy, Camshaft Timing Exhaust, LH
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13080-31030 |
Gear Assy, Camshaft Timing Exhaust, LH
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13080-31040 |
Gear Assy, Camshaft Timing Exhaust, LH
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13506 — Chain Sub-assy | ||||
| 13506-26010 |
Chain Sub-assy
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13506-31020 |
Chain Sub-assy
2005-08 → 2008-04
ended
|
4GRFSE GSE20 | — | |
| 13506-31031 |
Chain Sub-assy
2008-04 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13506-26010 |
Chain Sub-assy
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13506-26010 |
Chain Sub-assy
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13506-31031 |
Chain Sub-assy
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13506-26010 |
Chain Sub-assy
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13506-31031 |
Chain Sub-assy
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13507 — Chain Sub-assy, NO.2 | ||||
| 13507-31020 |
Chain Sub-assy, NO.2
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13507-31020 |
Chain Sub-assy, NO.2
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13507-31020 |
Chain Sub-assy, NO.2
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13511 — Camshaft | ||||
| 13501-0R010 note |
Camshaft
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13501-26010 note |
Camshaft
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13501-31051 |
Camshaft
2005-08 → 2008-05
ended
|
4GRFSE GSE20 | — | |
| 13501-31052 |
Camshaft
2008-05 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13501-0R010 note |
Camshaft
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13501-0R010 note |
Camshaft
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13501-26010 note |
Camshaft
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13501-26010 note |
Camshaft
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13501-31052 |
Camshaft
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13501-26010 |
Camshaft
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13501-31052 |
Camshaft
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13501-31081 |
Camshaft
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13512 — Camshaft, NO.2 | ||||
| 13502-0R010 note |
Camshaft, NO.2
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13502-26010 note |
Camshaft, NO.2
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13502-31021 |
Camshaft, NO.2
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13502-0R010 note |
Camshaft, NO.2
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13502-0R010 note |
Camshaft, NO.2
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13502-26010 note |
Camshaft, NO.2
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13502-26010 note |
Camshaft, NO.2
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13502-31021 |
Camshaft, NO.2
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13502-26010 |
Camshaft, NO.2
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13502-31021 |
Camshaft, NO.2
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13502-31050 |
Camshaft, NO.2
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13530 — Sprocket Assy, Idle | ||||
| 13530-31020 |
Sprocket Assy, Idle
2005-08 → 2006-10
ended
|
4GRFSE GSE20 | — | |
| 13530-31021 |
Sprocket Assy, Idle
2006-10 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13530-31021 |
Sprocket Assy, Idle
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13530-31021 |
Sprocket Assy, Idle
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13540 — Tensioner Assy, Chain, NO.1 | ||||
| 13540-26010 |
Tensioner Assy, Chain, NO.1
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13540-31021 |
Tensioner Assy, Chain, NO.1
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13540-26010 |
Tensioner Assy, Chain, NO.1
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13540-26010 |
Tensioner Assy, Chain, NO.1
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13540-31021 |
Tensioner Assy, Chain, NO.1
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13540-26010 |
Tensioner Assy, Chain, NO.1
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13540-31021 |
Tensioner Assy, Chain, NO.1
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13540-31031 |
Tensioner Assy, Chain, NO.1
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13550 — Tensioner Assy, Chain, NO.2 | ||||
| 13550-31020 |
Tensioner Assy, Chain, NO.2
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13550-31020 |
Tensioner Assy, Chain, NO.2
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13550-31020 |
Tensioner Assy, Chain, NO.2
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13559 — Slipper, Chain Tensioner | ||||
| 13559-0R010 |
Slipper, Chain Tensioner
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13559-31020 |
Slipper, Chain Tensioner
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13559-0R010 |
Slipper, Chain Tensioner
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13559-0R010 |
Slipper, Chain Tensioner
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13559-31020 |
Slipper, Chain Tensioner
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13559-0R010 note |
Slipper, Chain Tensioner
2010-08 → 2012-07
ended
|
2AD# ALE20 | — | |
| 13559-0R020 note |
Slipper, Chain Tensioner
2012-07 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13559-31020 |
Slipper, Chain Tensioner
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13560A — Tensioner Assy, Chain, NO.3 | ||||
| 13560-31020 |
Tensioner Assy, Chain, NO.3
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13560-31020 |
Tensioner Assy, Chain, NO.3
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13560-31020 |
Tensioner Assy, Chain, NO.3
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13561 — Damper, Chain Vibration, NO.1 | ||||
| 13561-0R010 |
Damper, Chain Vibration, NO.1
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13561-31021 |
Damper, Chain Vibration, NO.1
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13561-0R010 |
Damper, Chain Vibration, NO.1
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13561-0R010 |
Damper, Chain Vibration, NO.1
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13561-31021 |
Damper, Chain Vibration, NO.1
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13561-0R010 note |
Damper, Chain Vibration, NO.1
2010-08 → 2012-07
ended
|
2AD# ALE20 | — | |
| 13561-0R020 note |
Damper, Chain Vibration, NO.1
2012-07 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13561-31021 |
Damper, Chain Vibration, NO.1
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13562 — Damper, Chain Vibration, NO.2 | ||||
| 13562-31020 |
Damper, Chain Vibration, NO.2
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13562-31020 |
Damper, Chain Vibration, NO.2
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13562-31020 |
Damper, Chain Vibration, NO.2
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13711 — Valve, Intake | ||||
| 13711-0R010 |
Valve, Intake
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13711-31080 |
Valve, Intake
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13711-31080 |
Valve, Intake
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13711-51030 |
Valve, Intake
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13711-51030 |
Valve, Intake
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13711-31080 |
Valve, Intake
2010-08 → 2013-03
ended
|
4GRFSE GSE20 | — | |
| 13711-31081 |
Valve, Intake
2013-03 → 2013-04
ended
|
4GRFSE GSE20 | — | |
| 13711-31100 |
Valve, Intake
2010-08 → 2013-02
ended
|
2GRFSE GSE21 | — | |
| 13711-31101 |
Valve, Intake
2013-02 → 2013-04
ended
|
2GRFSE GSE21 | — | |
| 13711-51030 |
Valve, Intake
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13711B — Spring, Compression(FOR INNER) | ||||
| 90501-30030 |
Spring, Compression(FOR INNER)
2006-03 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 90501-33019 |
Spring, Compression(FOR INNER)
2005-08 → 2006-03
ended
|
4GRFSE GSE20 | — | |
| 90501-W0006 |
Spring, Compression(FOR INNER)
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90501-28039 |
Spring, Compression(FOR INNER)
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90501-28039 |
Spring, Compression(FOR INNER)
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90501-30030 |
Spring, Compression(FOR INNER)
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 90501-28039 |
Spring, Compression(FOR INNER)
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 90501-30030 |
Spring, Compression(FOR INNER)
2010-08 → 2013-04
ended
|
4GRFSE GSE20 | — | |
| 90501-35046 |
Spring, Compression(FOR INNER)
2010-08 → 2013-04
ended
|
2GRFSE GSE21 | — | |
| 13711E — Seal, Intake Valve Stem Oil | ||||
| 90913-02101 |
Seal, Intake Valve Stem Oil
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 90913-02124 note |
Seal, Intake Valve Stem Oil
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90913-W2001 note |
Seal, Intake Valve Stem Oil
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90913-02101 |
Seal, Intake Valve Stem Oil
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 90913-02124 note |
Seal, Intake Valve Stem Oil
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90913-02124 note |
Seal, Intake Valve Stem Oil
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90913-W2001 note |
Seal, Intake Valve Stem Oil
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90913-W2001 note |
Seal, Intake Valve Stem Oil
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90913-02101 |
Seal, Intake Valve Stem Oil
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 90913-02124 |
Seal, Intake Valve Stem Oil
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13715 — Valve, Exhaust | ||||
| 13715-0R010 |
Valve, Exhaust
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13715-31101 |
Valve, Exhaust
2005-08 → 2008-03
ended
|
4GRFSE GSE20 | — | |
| 13715-31102 |
Valve, Exhaust
2008-03 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13715-31102 |
Valve, Exhaust
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13715-51030 |
Valve, Exhaust
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13715-51030 |
Valve, Exhaust
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13715-31102 |
Valve, Exhaust
2010-08 → 2013-03
ended
|
4GRFSE GSE20 | — | |
| 13715-31103 |
Valve, Exhaust
2013-03 → 2013-04
ended
|
4GRFSE GSE20 | — | |
| 13715-31150 |
Valve, Exhaust
2010-08 → 2013-04
ended
|
2GRFSE GSE21 | — | |
| 13715-51030 |
Valve, Exhaust
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13715A — Seal, Exhaust Valve Stem Oil | ||||
| 90913-02112 |
Seal, Exhaust Valve Stem Oil
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 90913-02124 note |
Seal, Exhaust Valve Stem Oil
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90913-W2001 note |
Seal, Exhaust Valve Stem Oil
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90913-02112 |
Seal, Exhaust Valve Stem Oil
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 90913-02124 note |
Seal, Exhaust Valve Stem Oil
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90913-02124 note |
Seal, Exhaust Valve Stem Oil
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90913-W2001 note |
Seal, Exhaust Valve Stem Oil
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90913-W2001 note |
Seal, Exhaust Valve Stem Oil
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90913-02112 |
Seal, Exhaust Valve Stem Oil
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 90913-02124 |
Seal, Exhaust Valve Stem Oil
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13716 — Cap, Valve Stem | ||||
| 13716-75020 |
Cap, Valve Stem
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13716-75020 |
Cap, Valve Stem
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13716-75020 |
Cap, Valve Stem
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13734 — Seat, Valve Spring | ||||
| 13734-62020 |
Seat, Valve Spring
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 90562-13002 |
Seat, Valve Spring
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13734-33020 |
Seat, Valve Spring
2008-09 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13734-33020 |
Seat, Valve Spring
2008-09 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13734-62020 |
Seat, Valve Spring
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 90562-13002 |
Seat, Valve Spring
2008-08 → 2008-09
ended
|
2ADFHV ALE20 | — | |
| 13734-33020 |
Seat, Valve Spring
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13734-62020 |
Seat, Valve Spring
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13741 — Retainer, Valve Spring | ||||
| 13741-0R010 |
Retainer, Valve Spring
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13741-20021 |
Retainer, Valve Spring
2005-08 → 2006-03
ended
|
4GRFSE GSE20 | — | |
| 13741-31020 |
Retainer, Valve Spring
2006-03 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13741-0R010 |
Retainer, Valve Spring
2008-08 → 2008-12
ended
|
2ADFHV ALE20 | — | |
| 13741-31020 |
Retainer, Valve Spring
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13741-33020 |
Retainer, Valve Spring
2008-12 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13741-33020 |
Retainer, Valve Spring
2008-12 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13741-31020 |
Retainer, Valve Spring
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13741-33020 |
Retainer, Valve Spring
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13741A — Lock, Valve Spring Retainer | ||||
| 90913-03021 |
Lock, Valve Spring Retainer
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 90913-03028 |
Lock, Valve Spring Retainer
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 90913-03021 |
Lock, Valve Spring Retainer
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 90913-03021 |
Lock, Valve Spring Retainer
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 90913-03028 |
Lock, Valve Spring Retainer
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 90913-03021 |
Lock, Valve Spring Retainer
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 90913-03028 |
Lock, Valve Spring Retainer
2010-08 → —
|
2GRFSE,4GRFSE GSE2# | — | |
| 13750 — Adjuster Assy, Valve Lash | ||||
| 13750-0R010 |
Adjuster Assy, Valve Lash
2005-11 → 2007-07
ended
|
2ADFHV ALE20 | — | |
| 13750-0R020 |
Adjuster Assy, Valve Lash
2007-07 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13750-31030 |
Adjuster Assy, Valve Lash
2008-05 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13750-75020 |
Adjuster Assy, Valve Lash
2005-08 → 2008-05
ended
|
4GRFSE GSE20 | — | |
| 13750-0R020 note |
Adjuster Assy, Valve Lash
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13750-0R020 note |
Adjuster Assy, Valve Lash
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13750-26010 note |
Adjuster Assy, Valve Lash
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13750-26010 note |
Adjuster Assy, Valve Lash
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13750-31030 |
Adjuster Assy, Valve Lash
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13750-0R020 note |
Adjuster Assy, Valve Lash
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13750-26010 note |
Adjuster Assy, Valve Lash
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13750-31020 |
Adjuster Assy, Valve Lash
2012-06 → —
|
4GRFSE GSE20 | — | |
| 13750-31030 |
Adjuster Assy, Valve Lash
2010-08 → —
|
2GRFSE GSE21 | — | |
| 13750-31030 |
Adjuster Assy, Valve Lash
2010-08 → 2012-06
ended
|
4GRFSE GSE20 | — | |
| 13801 — Arm Sub-assy, Valve Rocker, NO.1 | ||||
| 13801-0R010 |
Arm Sub-assy, Valve Rocker, NO.1
2005-11 → 2008-08
ended
|
2ADFHV ALE20 | — | |
| 13801-23011 |
Arm Sub-assy, Valve Rocker, NO.1
2005-08 → 2008-08
ended
|
4GRFSE GSE20 | — | |
| 13801-0R010 note |
Arm Sub-assy, Valve Rocker, NO.1
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13801-0R010 note |
Arm Sub-assy, Valve Rocker, NO.1
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13801-23011 |
Arm Sub-assy, Valve Rocker, NO.1
2008-08 → 2010-08
ended
|
4GRFSE GSE20 | — | |
| 13801-26010 note |
Arm Sub-assy, Valve Rocker, NO.1
2008-08 → 2009-08
ended
|
2ADFHV ALE20 RHD SPO | — | |
| 13801-26010 note |
Arm Sub-assy, Valve Rocker, NO.1
2008-08 → 2010-08
ended
|
2ADFHV ALE20 LUX;2ADFHV ALE20 +2 | — | |
| 13801-0R010 note |
Arm Sub-assy, Valve Rocker, NO.1
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13801-23011 |
Arm Sub-assy, Valve Rocker, NO.1
2010-08 → —
|
4GRFSE GSE20 | — | |
| 13801-26010 note |
Arm Sub-assy, Valve Rocker, NO.1
2010-08 → 2012-08
ended
|
2AD# ALE20 | — | |
| 13801-38020 |
Arm Sub-assy, Valve Rocker, NO.1
2010-08 → —
|
2GRFSE GSE21 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
