Toyota Lexus IS2###/3###

2013-04 → present · chassis ASE30,AVE30,GSE30 · catalogue 242530 · Europe

Supported model Data version 2018-09

Suspension Crossmember & Under Cover

34 part groups · 4 illustrations

PNC	Description
48691D	Damper, Suspension Tower
51201	Crossmember Sub-assy, Front Suspension
51206A	Member Sub-assy, Rear Suspension
51210B	Crossmember Assy, Frame, NO.1
51217D	Member, Front Suspension, NO.2 Upper
51219	Protector, Front Suspension Member, Lwr
51220	Crossmember Assy, Frame, NO.2
51224B	Plate, Front Suspension Menber Brace, RH
51225D	Plate, Front Suspension Menber Brace, LH
51226B	Plate, Front Suspension Member, NO.2
51249A	Damper, Rear Suspension Member
51408B	Cover Sub-assy, Engine Under, RH
51409B	Cover Sub-assy, Engine Under, LH
51441D	Cover, Engine Under
51442E	Cover, Engine Under, NO.2
51443C	Cover, Engine Under, Rear RH
51444A	Cover, Engine Under, Rear LH
51447D	Cover, Engine Under, NO.4 Center
51451D	Screw, NO.1
51453	Silencer, Engine Under Cover, Front
52203F	Stopper Sub-assy, Rear Suspension Member, Lower RH
52204C	Stopper Sub-assy, Rear Suspension Member, Lower LH
52205H	Cushion Sub-assy, Body Mounting, Rear RH
52206C	Cushion Sub-assy, Body Mounting, Rear LH
52255B	Brace, Front Suspension Member
52271D	Cushion, Rear Suspension Member Body Mounting, Front
52272B	Cushion, Rear Suspension Member Body Mounting, Front Lower
52274A	Stopper, Rear Suspension Member, Lower LH
52275A	Cushion, Rear Suspension Member Body Mounting, Rear
52277B	Stopper, Rear Suspension Member, Rear Upper
52278C	Stopper, Rear Suspension Member, Rear Lower
52295	Brace, Rear Suspension Member, RH
52296	Brace, Rear Suspension Member, LH
57533A	Brace, Front Floor, Center

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
