Toyota Celica
1981-08 → 1985-12 · chassis AA63,TA60,SA63,RA6#,MA61 · catalogue 252230 · Europe
Discontinued model
Data version 1986-05
Throttle Link & Valve Lever (ATM)
20 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 35505 | Lever Sub-assy, Manual Valve |
| 35506 | Shaft Sub-assy, Manual Valve Lever |
| 35506C | Pin, Slotted Spring (FOR MANUAL VALVE LEVER SHAFT) |
| 35506F | Seal, Oil (FOR MANUAL VALVE LEVER SHAFT) |
| 35506H | Spacer (FOR MANUAL VALVE LEVER SHAFT) |
| 35520 | Cable Assy, Throttle |
| 35520A | Pin, Throttle Cable |
| 35520B | Ring, O(FOR THROTTLE CABLE) |
| 35523 | Clamp, Throttle Cable |
| 35524 | Clamp, Throttle Cable, NO.2 |
| 35525 | Bracket, Throttle Cable |
| 35526 | Bracket, Throttle Cable Guide |
| 35527 | Insulator, Throttle Cable Heat |
| 35556 | Shaft, Parking Lock Pawl |
| 35556E | Ring, E (FOR PARKING LOCK PAWL SHAFT) |
| 35557 | Pawl, Parking Lock |
| 35557A | Spring, Torsion (FOR PARKING LOCK PAWL) |
| 35572 | Lever, Transmission Control Shaft, RH |
| 35585 | Rod, Parking Lock |
| 35595 | Bracket, Parking Lock Pawl |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
