Toyota Celica
1989-09 → 1993-09 · chassis AT180,ST18# · catalogue 252460 · Europe
Discontinued model
Data version 1994-04
Package Tray Panel & Luggage Compartment Mat
24 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 64033B | Grille Sub-assy, Rear Speaker, RH |
| 64034B | Grille Sub-assy, Rear Speaker, LH |
| 64271B | Clip(FOR ROOM PARTITION BOARD) |
| 64271F | Trim, Room Partition |
| 64271G | Board, Room Partition, RH |
| 64272B | Board, Room Partition, LH |
| 64330 | Panel Assy, Package Tray Trim |
| 64330A | Clip(FOR PACKAGE TRAY TRIM PANEL) |
| 64330E | Plug(FOR PACKAGE TRAY TRIM PANEL) |
| 64711 | Mat, Luggage Compartment Floor |
| 64712 | Cover, Luggage Compartment Trim, RH |
| 64712C | Clip(FOR LUGGAGE COMPARTMENT TRIM COVER) |
| 64713 | Cover, Luggage Compartment Trim, LH |
| 64716C | Clip(FOR LUGGAGE COMPARTMENT TRIM REAR COVER) |
| 64716G | Cover, Luggage Compartment Trim, Rear |
| 64717A | Cover, Luggage Compartment Trim, Front |
| 64719A | Cover, Luggage Compartment Door |
| 64719B | Clip(FOR LUGGAGE COMPARTMENT DOOR) |
| 64726A | Clip, Luggage Trim, Rear |
| 64726D | Clip, Luggage Trim, Rear |
| 64751A | Bracket, Luggage Compartment Cover, NO.1 |
| 64770 | Cover Assy, Spare Wheel |
| 64777 | Clamp, Spare Wheel Cover |
| 89189A | Bracket, Luggage Compartment Trim |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
