Toyota Celica
1987-08 → 1989-08 · chassis AT160,ST16# · catalogue 252550 · Europe
Discontinued model
Data version 1990-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82151 — Wire, Front Door, RH | ||||
| 82151-20250 |
Wire, Front Door, RH
1987-08 → 1989-08
ended
|
AT160 | — | |
| 82151-20260 |
Wire, Front Door, RH
1987-08 → 1988-08
ended
|
ST162 CP,LB | — | |
| 82151-20260 note |
Wire, Front Door, RH
1987-08 → 1989-08
ended
|
AT160 | — | |
| 82151-20260 |
Wire, Front Door, RH
1988-08 → 1989-08
ended
|
ST162 (CP,LB) LHD | — | |
| 82151-20291 note |
Wire, Front Door, RH
1987-08 → 1988-05
ended
|
ST162 (CP,LB) RHD | — | |
| 82151-20291 |
Wire, Front Door, RH
1987-08 → 1988-05
ended
|
ST165 RHD | — | |
| 82151-20292 |
Wire, Front Door, RH
1988-05 → 1989-08
ended
|
ST165 RHD | — | |
| 82151-20292 note |
Wire, Front Door, RH
1988-05 → 1989-08
ended
|
ST162 (CP,LB) RHD | — | |
| 82151-20310 note |
Wire, Front Door, RH
1987-08 → 1988-05
ended
|
AT160 TWC | — | |
| 82151-20320 note |
Wire, Front Door, RH
1987-08 → 1988-08
ended
|
AT160 TWC | — | |
| 82151-20320 |
Wire, Front Door, RH
1987-08 → 1989-08
ended
|
ST165 LHD | — | |
| 82151-20320 note |
Wire, Front Door, RH
1987-08 → 1989-08
ended
|
ST162 (CP,LB) LHD | — | |
| 82151-20320 note |
Wire, Front Door, RH
1988-08 → 1989-08
ended
|
AT160 TWC | — | |
| 82151-20331 |
Wire, Front Door, RH
1987-08 → 1989-08
ended
|
ST162 CVT LHD | — | |
| 82151-20520 |
Wire, Front Door, RH
1987-08 → 1988-05
ended
|
ST162 CVT RHD | — | |
| 82151-20521 |
Wire, Front Door, RH
1988-05 → 1989-08
ended
|
ST162 CVT RHD | — | |
| 82151-2B040 |
Wire, Front Door, RH
1988-08 → 1989-08
ended
|
ST162 LB RHD | — | |
| 82152 — Wire, Front Door, LH | ||||
| 82152-20230 |
Wire, Front Door, LH
1987-08 → 1989-08
ended
|
AT160 | — | |
| 82152-20240 |
Wire, Front Door, LH
1988-08 → 1989-08
ended
|
ST162 (CP,LB) LHD | — | |
| 82152-20240 |
Wire, Front Door, LH
1987-08 → 1988-08
ended
|
ST162 CP,LB | — | |
| 82152-20240 note |
Wire, Front Door, LH
1987-08 → 1989-08
ended
|
AT160 | — | |
| 82152-20270 |
Wire, Front Door, LH
1987-08 → 1988-05
ended
|
ST165 RHD | — | |
| 82152-20270 note |
Wire, Front Door, LH
1987-08 → 1988-05
ended
|
ST162 (CP,LB) RHD | — | |
| 82152-20271 note |
Wire, Front Door, LH
1988-05 → 1989-08
ended
|
ST162 (CP,LB) RHD | — | |
| 82152-20271 |
Wire, Front Door, LH
1988-05 → 1989-08
ended
|
ST165 RHD | — | |
| 82152-20290 note |
Wire, Front Door, LH
1987-08 → 1988-05
ended
|
AT160 TWC | — | |
| 82152-20300 note |
Wire, Front Door, LH
1987-08 → 1989-08
ended
|
ST162 (CP,LB) LHD | — | |
| 82152-20300 |
Wire, Front Door, LH
1987-08 → 1989-08
ended
|
ST165 LHD | — | |
| 82152-20300 note |
Wire, Front Door, LH
1987-08 → 1988-08
ended
|
AT160 TWC | — | |
| 82152-20300 note |
Wire, Front Door, LH
1988-08 → 1989-08
ended
|
AT160 TWC | — | |
| 82152-20311 |
Wire, Front Door, LH
1987-08 → 1989-08
ended
|
ST162 CVT LHD | — | |
| 82152-20460 |
Wire, Front Door, LH
1987-08 → 1988-05
ended
|
ST162 CVT RHD | — | |
| 82152-20461 |
Wire, Front Door, LH
1988-05 → 1989-08
ended
|
ST162 CVT RHD | — | |
| 82152-20810 |
Wire, Front Door, LH
1988-08 → 1989-08
ended
|
ST162 LB RHD | — | |
| 82161 — Wire, Floor | ||||
| 82161-2B280 |
Wire, Floor
1987-08 → 1989-08
ended
|
ST162 (CP,CVT) RHD | — | |
| 82161-2B300 |
Wire, Floor
1987-08 → 1988-05
ended
|
ST162 LB RHD | — | |
| 82161-2B301 |
Wire, Floor
1988-05 → 1989-08
ended
|
ST162 LB RHD | — | |
| 82161-2B310 |
Wire, Floor
1987-08 → 1989-08
ended
|
AT160 CP | — | |
| 82161-2B320 |
Wire, Floor
1987-08 → 1989-08
ended
|
ST162 (CP,CVT) LHD | — | |
| 82161-2B330 note |
Wire, Floor
1987-08 → 1989-08
ended
|
ST162 CP LHD | — | |
| 82161-2B330 note |
Wire, Floor
1987-08 → 1989-08
ended
|
AT160 CP TWC | — | |
| 82161-2B340 |
Wire, Floor
1987-08 → 1989-08
ended
|
AT160 LB | — | |
| 82161-2B350 |
Wire, Floor
1987-08 → 1989-08
ended
|
ST162 LB LHD | — | |
| 82161-2B360 note |
Wire, Floor
1987-08 → 1989-08
ended
|
AT160 LB TWC | — | |
| 82161-2B360 note |
Wire, Floor
1987-08 → 1989-08
ended
|
ST162 LB LHD | — | |
| 82161-2B450 |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 RHD | — | |
| 82161-2B460 note |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 RHD | — | |
| 82161-2B470 |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 LHD | — | |
| 82161-2B480 note |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 LHD | — | |
| 82161-2B490 note |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 LHD | — | |
| 82161-2B500 note |
Wire, Floor
1987-10 → 1989-08
ended
|
ST165 LHD | — | |
| 82162 — Wire, Floor, NO.2 | ||||
| 82162-20280 |
Wire, Floor, NO.2
1987-08 → 1989-08
ended
|
ST162 CVT LHD | — | |
| 82162-20280 |
Wire, Floor, NO.2
1987-08 → 1989-08
ended
|
ST162 (CP,LB) LHD | — | |
| 82162-20290 |
Wire, Floor, NO.2
1987-08 → 1989-08
ended
|
ST162 (CP,LB) RHD | — | |
| 82167 — Wire, Seat, NO.1 | ||||
| 82167-20020 |
Wire, Seat, NO.1
1987-08 → 1989-08
ended
|
ST162 CP,LB | — | |
| 82167-20020 |
Wire, Seat, NO.1
1987-08 → 1989-08
ended
|
ST162 CVT LHD | — | |
| 82167-20020 |
Wire, Seat, NO.1
1987-08 → 1989-08
ended
|
ST165 | — | |
| 82171 — Wire, Roof, NO.1 | ||||
| 82171-20181 |
Wire, Roof, NO.1
1987-08 → 1989-08
ended
|
ST16# RHD | — | |
| 82171-20200 |
Wire, Roof, NO.1
1987-08 → 1989-08
ended
|
AT160,ST16# LHD | — | |
| 82171-20210 note |
Wire, Roof, NO.1
1987-08 → 1989-08
ended
|
AT160,ST16# (CP,LB) LHD | — | |
| 82171-20290 note |
Wire, Roof, NO.1
1987-08 → 1989-08
ended
|
ST16# (CP,LB) RHD | — | |
| 82172 — Wire, Roof, NO.2 | ||||
| 82172-20010 |
Wire, Roof, NO.2
1987-08 → 1989-08
ended
|
AT160,ST16# CP,LB | — | |
| 82181 — Wire, Luggage Room, NO.1 | ||||
| 82181-20180 |
Wire, Luggage Room, NO.1
1987-08 → 1989-08
ended
|
AT160,ST162 CP,CVT | — | |
| 82181-20190 |
Wire, Luggage Room, NO.1
1987-08 → 1989-08
ended
|
AT160,ST162 LB | — | |
| 82181-20310 |
Wire, Luggage Room, NO.1
1987-10 → 1989-08
ended
|
ST165 | — | |
| 82184 — Wire, Back Door, NO.1 | ||||
| 82184-20050 |
Wire, Back Door, NO.1
1987-08 → 1989-08
ended
|
AT160,ST16# LB | — | |
| 82185 — Wire, Back Door, NO.2 | ||||
| 82185-20190 |
Wire, Back Door, NO.2
1987-08 → 1989-08
ended
|
AT160,ST162 LB | — | |
| 82185-20200 |
Wire, Back Door, NO.2
1987-08 → 1988-08
ended
|
ST165 | — | |
| 82185-20200 note |
Wire, Back Door, NO.2
1987-08 → 1988-08
ended
|
AT160,ST162 LB | — | |
| 82185-20201 |
Wire, Back Door, NO.2
1988-08 → 1989-08
ended
|
ST165 | — | |
| 82185-20201 note |
Wire, Back Door, NO.2
1988-08 → 1989-08
ended
|
AT160,ST162 LB | — | |
| 82187 — Wire, Rear Window, NO.2 | ||||
| 82187-20080 |
Wire, Rear Window, NO.2
1987-08 → 1989-08
ended
|
AT160,ST162 CP | — | |
| 82187-20100 |
Wire, Rear Window, NO.2
1987-08 → 1989-08
ended
|
AT160,ST16# LB | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
