Toyota Celica
1993-11 → 1999-08 · chassis AT200,ST20# · catalogue 252570 · Europe
Discontinued model
Data version 2000-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86211 — Bracket, Radio, NO.1 | ||||
| 86211-20360 |
Bracket, Radio, NO.1
1993-11 → —
|
AT200,ST20# RHD | — | |
| 86211-20370 |
Bracket, Radio, NO.1
1993-11 → —
|
AT200,ST20# LHD | — | |
| 86212 — Bracket, Radio, NO.2 | ||||
| 86212-20360 |
Bracket, Radio, NO.2
1993-11 → —
|
AT200,ST20# RHD | — | |
| 86212-20370 |
Bracket, Radio, NO.2
1993-11 → —
|
AT200,ST20# LHD | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
