Toyota Corona
1973-08 → 1979-05 · chassis RT10#,11# · catalogue 261230 · Europe
Discontinued model
Data version 1979-05
Quarter Window
41 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 62711 | Glass, Quarter Window, RH |
| 62712 | Glass, Quarter Window, LH |
| 62731 | Plate, Quarter OR Side Window Hinge |
| 62732 | Plate, Quarter OR Side Window Hinge Finish |
| 62732A | Gasket(FOR QUARTER WINDOW HINGE FINISH PLATE) |
| 62733 | Retainer, Quarter OR Side Window Hinge |
| 62734 | Spacer, Quarter Window Hinge |
| 62739 | Support, Quarter Window Hinge |
| 62741 | Weatherstrip, Quarter Window, RH |
| 62742 | Weatherstrip, Quarter Window, LH |
| 62910 | Lock Assy, Quarter OR Side Window, RH |
| 62910A | Gasket(FOR QUARTER OR SIDE WINDOW LOCK OR HINGE) |
| 62918 | Spacer, Quarter Window Lock Support |
| 62920 | Lock Assy, Quarter Window, LH |
| 67875 | Weatherstrip, Rear Quarter Window Glass, RH |
| 67876 | Weatherstrip, Rear Quarter Window Glass, LH |
| 68113 | Glass, Quarter Window, RH |
| 68114 | Glass, Quarter Window, LH |
| 68167 | Weatherstrip, Rear Quarter Front Corner, RH |
| 68168 | Weatherstrip, Rear Quarter Front Corner, LH |
| 68169 | Clip, Corner Weatherstrip |
| 69290 | Handle Assy, Quarter Window Regulator |
| 69290B | Ring, Snap(FOR QUARTER WINDOW REGULATOR HANDLE) |
| 69290C | Escutcheon(FOR QUARTER WINDOW REGULATOR HANDLE) |
| 69290D | Seal(FOR QUARTER WINDOW REGULATOR HANDLE) |
| 69830 | Regulator Assy, Rear Quarter Window, RH |
| 69840 | Regulator Assy, Rear Quarter Window, LH |
| 69891 | Stopper, Quarter Window Glass, Upper |
| 69893 | Stopper,Quarter Window Glass Lower, RH |
| 69894 | Stopper, Quarter Window Glass Lower, LH |
| 69907 | Guide Sub-assy, Quarter Regulator Roller, RH |
| 69907A | Bolt, Stud, NO.1(FOR QUARTER REGULATOR ROLLER GUIDE) |
| 69907B | Bolt, Stud, NO.2(FOR QUARTER REGULATOR ROLLER GUIDE) |
| 69908 | Guide Sub-assy, Quarter Regulator Roller, LH |
| 69961 | Plate, Rear Quarter Glass Bracket |
| 69966 | Bracket, Rear Quarter Window Glass, RH |
| 69967 | Bracket, Rear Quarter Window Glass, LH |
| 69972 | Pin, Quarter Glass Channel Setting |
| 69987 | Spacer, Quarter Glass Belt |
| 69988 | Spacer, Quarter Window Glass |
| 69995 | Spacer(FOR QUARTER REGULATOR ROLLER GUIDE) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
