Toyota Corona

1973-08 → 1979-05 · chassis RT10#,11# · catalogue 261230 · Europe

Discontinued model Data version 1979-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Headlamp Cleaner

17 part groups · 2 illustrations

Illustrations

Figure ME4397C ME4397C 1974-09 → 1975-09 Figure ME4496F ME4496F 1975-09 → 1978-08

Part groups

PNCDescription
85110A Motor Assy, Headlamp Cleaner
85221A Blade Assy, Headlamp Cleaner
85230C Bracket Assy, Headlamp Cleaner
85272 Cable Sub-assy, Headlamp Cleaner, RH
85273 Cable Sub-assy, Headlamp Cleaner, LH
85275 Wiring Sub-assy, Headlamp Cleaner
85278 Relay Assy, Headlamp Cleaner Control
85280 Gear And Blade Sub-assy, Headlamp Cleaner
85282 Holder Assy, Headlamp Cleaner Washer Jar
85284 Hose Assy, Headlamp Cleaner Washer
85310A Motor And Pump Assy, Headlamp Cleaner Washer
85330B Bush, Headlamp Cleaner Washer Jar
85341 Nozzle, Headlamp Cleaner Washer
85348A Joint, Headlamp Cleaner Hose, NO.1
85370A Hose Assy, Headlamp Cleaner Washer, NO.1
85371A Hose, Headlamp Cleaner(FROM MOTOR TO JOINT)
85373A Hose, Headlamp Cleaner Washer (FROM JOINT TO NOZZLE)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
