Toyota Corona FR
1982-01 → 1999-07 · chassis CT14#,RT14#,ST141,TT14#,YT140 · catalogue 261250 · Europe
Discontinued model
Data version 2000-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 17700 — Cleaner Assy, Air | ||||
| 17700-26290 |
Cleaner Assy, Air
1982-10 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17700-26290 |
Cleaner Assy, Air
1982-01 → 1982-10
ended
|
2T TT140;3T TT141 RHD;3T +6 | — | |
| 17700-26300 note |
Cleaner Assy, Air
1982-01 → 1982-10
ended
|
2T,3T TT14# SED LHD +4 | — | |
| 17700-26300 note |
Cleaner Assy, Air
1982-10 → 1983-10
ended
|
2T TT140 SED RHD +2 | — | |
| 17700-26300 note |
Cleaner Assy, Air
1982-10 → 1984-12
ended
|
3T TT141 RHD | — | |
| 17700-31262 |
Cleaner Assy, Air
1982-06 → 1983-12
ended
|
12RM RT140 | — | |
| 17700-35250 |
Cleaner Assy, Air
1984-08 → 1985-08
ended
|
22REC RT142 | — | |
| 17700-35260 |
Cleaner Assy, Air
1985-08 → 1986-12
ended
|
22REC RT142 | — | |
| 17700-64010 |
Cleaner Assy, Air
1986-01 → 1999-07
ended
|
2C CT141 | — | |
| 17700-64020 |
Cleaner Assy, Air
1982-01 → 1983-12
ended
|
1C CT140 | — | |
| 17700-72060 |
Cleaner Assy, Air
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17700-72140 note |
Cleaner Assy, Air
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17700-74020 |
Cleaner Assy, Air
1983-04 → 1985-08
ended
|
2SC ST141 | — | |
| 17700-74060 |
Cleaner Assy, Air
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17700A — Nut, Wing(FOR AIR CLEANER) | ||||
| 90175-06003 |
Nut, Wing(FOR AIR CLEANER)
1982-01 → 1999-07
ended
|
12RM RT140 | — | |
| 90175-06003 |
Nut, Wing(FOR AIR CLEANER)
1982-01 → 1999-07
ended
|
2S# ST141 | — | |
| 90175-06003 |
Nut, Wing(FOR AIR CLEANER)
1982-01 → 1999-07
ended
|
2T,3T TT14# | — | |
| 90175-06003 |
Nut, Wing(FOR AIR CLEANER)
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17700F — Bolt, Stud(FOR AIR CLEANER SETTING) | ||||
| 90116-06024 |
Bolt, Stud(FOR AIR CLEANER SETTING)
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 90116-06142 |
Bolt, Stud(FOR AIR CLEANER SETTING)
1982-06 → 1983-12
ended
|
12RM RT140 | — | |
| 90116-06222 note |
Bolt, Stud(FOR AIR CLEANER SETTING)
1982-01 → 1985-08
ended
|
2T,3T TT14# | — | |
| 90116-06309 |
Bolt, Stud(FOR AIR CLEANER SETTING)
1983-04 → 1986-12
ended
|
2S# ST141 | — | |
| 17705 — Cap Sub-assy, Air Cleaner | ||||
| 17705-26080 |
Cap Sub-assy, Air Cleaner
1982-01 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17705-31033 |
Cap Sub-assy, Air Cleaner
1982-06 → 1983-12
ended
|
12RM RT140 | — | |
| 17705-35120 |
Cap Sub-assy, Air Cleaner
1984-08 → 1986-12
ended
|
22REC RT142 | — | |
| 17705-64010 |
Cap Sub-assy, Air Cleaner
1982-01 → 1983-12
ended
|
1C CT140 | — | |
| 17705-64010 |
Cap Sub-assy, Air Cleaner
1986-01 → 1999-07
ended
|
2C CT141 | — | |
| 17705-71020 |
Cap Sub-assy, Air Cleaner
1986-12 → 1992-11
ended
|
2Y YT140 | — | |
| 17705-73080 |
Cap Sub-assy, Air Cleaner
1992-11 → 1999-07
ended
|
2Y YT140 | — | |
| 17705-74020 |
Cap Sub-assy, Air Cleaner
1983-04 → 1986-12
ended
|
2S# ST141 | — | |
| 17730 — Precleaner Assy, Air W/Hose | ||||
| 17730-72010 note |
Precleaner Assy, Air W/Hose
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17730-74010 |
Precleaner Assy, Air W/Hose
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17730-74010 note |
Precleaner Assy, Air W/Hose
1986-12 → 1999-07
ended
|
2C CT141 4F | — | |
| 17744 — Cup, Precleaner | ||||
| 17744-13010 note |
Cup, Precleaner
1982-01 → 1984-04
ended
|
2T,3T TT14# | — | |
| 17744-16010 note |
Cup, Precleaner
1986-12 → 1999-07
ended
|
2C CT141 4F | — | |
| 17744-16010 |
Cup, Precleaner
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17744-16010 note |
Cup, Precleaner
1984-04 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17801 — Element Sub-assy, Air Cleaner Filter | ||||
| 17801-25010 |
Element Sub-assy, Air Cleaner Filter
1982-01 → 1985-08
ended
|
12RM RT140 | — | |
| 17801-25010 |
Element Sub-assy, Air Cleaner Filter
1982-01 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17801-31080 note |
Element Sub-assy, Air Cleaner Filter
1982-01 → 1985-08
ended
|
2T TT140;3T TT141 RHD;3T +6 | — | |
| 17801-34060 |
Element Sub-assy, Air Cleaner Filter
1983-04 → 1986-12
ended
|
2S# ST141 | — | |
| 17801-34070 |
Element Sub-assy, Air Cleaner Filter
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17801-41110 |
Element Sub-assy, Air Cleaner Filter
1984-08 → 1986-12
ended
|
22REC RT142 | — | |
| 17801-64010 |
Element Sub-assy, Air Cleaner Filter
1986-01 → 1999-07
ended
|
2C CT141 | — | |
| 17801-64020 |
Element Sub-assy, Air Cleaner Filter
1982-01 → 1983-12
ended
|
1C CT140 | — | |
| 17805 — Connector Sub-assy, Intake Air | ||||
| 17805-63060 |
Connector Sub-assy, Intake Air
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17841 — Gasket, Filter Element | ||||
| 17841-31020 |
Gasket, Filter Element
1982-01 → 1985-08
ended
|
12RM RT140 | — | |
| 17841-31020 |
Gasket, Filter Element
1982-01 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17841-33011 |
Gasket, Filter Element
1983-04 → 1986-12
ended
|
2S# ST141 | — | |
| 17845 — Gasket, Air Cleaner Cap | ||||
| 17845-15020 |
Gasket, Air Cleaner Cap
1983-04 → 1986-12
ended
|
2S# ST141 | — | |
| 17845-25010 |
Gasket, Air Cleaner Cap
1982-01 → 1982-10
ended
|
12RM RT140 | — | |
| 17845-25010 |
Gasket, Air Cleaner Cap
1982-01 → 1982-10
ended
|
2T,3T TT14# | — | |
| 17845-42010 note |
Gasket, Air Cleaner Cap
1982-10 → 1985-08
ended
|
12RM RT140 | — | |
| 17845-42010 note |
Gasket, Air Cleaner Cap
1982-10 → 1985-08
ended
|
2T,3T TT14# | — | |
| 17848 — Gasket, Air Cleaner TO Carburetor | ||||
| 17848-35010 |
Gasket, Air Cleaner TO Carburetor
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17848-35010 |
Gasket, Air Cleaner TO Carburetor
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 17881 — Hose, Air Cleaner, NO.1 | ||||
| 17881-16210 note |
Hose, Air Cleaner, NO.1
1990-07 → 1999-07
ended
|
2Y YT140 | — | |
| 17881-34040 note |
Hose, Air Cleaner, NO.1
1982-10 → 1984-12
ended
|
3T TT141 RHD | — | |
| 17881-34040 note |
Hose, Air Cleaner, NO.1
1982-10 → 1983-10
ended
|
2T TT140 SED RHD +2 | — | |
| 17881-34040 note |
Hose, Air Cleaner, NO.1
1982-01 → 1982-10
ended
|
2T,3T TT14# SED LHD +4 | — | |
| 17881-35010 |
Hose, Air Cleaner, NO.1
1984-08 → 1986-12
ended
|
22REC RT142 | — | |
| 17881-64150 note |
Hose, Air Cleaner, NO.1
1986-12 → 1999-07
ended
|
2C CT141 4F | — | |
| 17881-74030 |
Hose, Air Cleaner, NO.1
1983-11 → 1985-02
ended
|
2SC ST141 | — | |
| 17881-74040 |
Hose, Air Cleaner, NO.1
1985-02 → 1985-08
ended
|
2SC ST141 | — | |
| 17881-74040 |
Hose, Air Cleaner, NO.1
1985-08 → 1986-12
ended
|
2SC ST141 | — | |
| 17881-74040 note |
Hose, Air Cleaner, NO.1
1986-12 → 1990-07
ended
|
2Y YT140 | — | |
| 17881-74080 |
Hose, Air Cleaner, NO.1
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 17882-31040 |
Hose, Air Cleaner, NO.1
1983-04 → 1983-11
ended
|
2SC ST141 | — | |
| 17881A — Clamp(FOR AIR CLEANER HOSE, NO.1) | ||||
| 90460-01024 note |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 96111-10460 |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1983-04 → 1986-12
ended
|
2SC ST141 | — | |
| 96111-10460 note |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1986-12 → 1999-07
ended
|
2Y YT140 | — | |
| 96111-10600 note |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1985-08 → 1986-12
ended
|
2S ST141 | — | |
| 96111-10670 note |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1986-12 → 1999-07
ended
|
2C CT141 4F | — | |
| 96111-10800 |
Clamp(FOR AIR CLEANER HOSE, NO.1)
1984-08 → 1986-12
ended
|
22REC RT142 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
