Toyota GT86/86

2012-04 → 2016-07 · chassis ZN6 · catalogue 264210 · Europe

Supported model Data version 2017-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Side Moulding

20 part groups · 2 illustrations

Illustrations

Figure 753503A 753503A 2012-04 → — Figure 752663 752663 2012-04 → —

Part groups

PNCDescription
67863F Weatherstrip, Front Door, NO.2 RH
67864F Weatherstrip, Front Door, NO.2 LH
67869M Clip, Door Weatherstrip
75551 Moulding, Roof Drip Side Finish, RH
75552 Moulding, Roof Drip Side Finish, LH
75555D Moulding, Roof Drip Side Finish, Center RH
75556C Moulding, Roof Drip Side Finish, Center LH
75561 Clip, Roof Drip Side Finish Moulding, NO.1
75601A Moulding Sub-assy, Front Fender, RH
75602A Moulding Sub-assy, Front Fender, LH
75850A Moulding Assy, Body Rocker Panel, RH
75853 Protector, Rear Fender, RH
75854 Protector, Rear Fender, LH
75860A Moulding Assy, Body Rocker Panel, LH
75867A Clip, Rocker Panel Moulding
75867C Clip, Rocker Panel Moulding
75868B Clip, Rocker Panel Moulding, NO.2
75871A Clip (FOR FRONT FENDER MOULDING NO.1)
75895A Tape, Moulding, NO.1
76923B Retainer, Side Mudguard
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
