Toyota Carina 2
1987-12 → 1992-03 · chassis AT17#,ST171,CT171 · catalogue 271520 · Europe
Discontinued model
Data version 1993-08
Deck Board & Deck Trim Cover
33 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 64033A | Grille Sub-assy, Rear Speaker, RH |
| 64034A | Grille Sub-assy, Rear Speaker, LH |
| 64323A | Clamp, Package Tray Trim, RH |
| 64323B | Clamp, Tonneau Cover |
| 64324A | Clamp, Package Tray Trim, LH |
| 64330D | Panel Assy, Package Tray Trim |
| 64333B | Cover, Package Tray Trim Side, RH |
| 64349B | Cover, Package Tray Trim Side, LH |
| 64373A | Stopper, Package Tray Trim |
| 64381A | Hanger, Package Tray Trim |
| 64395 | Pin, Package Tray Trim Hinge |
| 64702B | Stopper, Washer Tank Cover |
| 64702C | Knob, Washer Tank Cover |
| 64707B | Cover Sub-assy, Quarter Trim Jack |
| 64709J | Cover Sub-assy, Deck Trim Pocket |
| 64714B | Plug, Hole(FOR DECK TRIM SIDE COVER) |
| 64714E | Clip(FOR DECK TRIM SIDE COVER) |
| 64716D | Cover, Deck Trim, Rear |
| 64716E | Clip(FOR DECK TRIM REAR COVER) |
| 64716F | Plug, Hole(FOR DECK TRIM REAR COVER) |
| 64730C | Board, Deck Trim Side, RH |
| 64740B | Board, Deck Trim Side, LH |
| 64770D | Cover Assy, Spare Wheel |
| 64777A | Clamp, Spare Wheel Cover |
| 64901A | Retractor Sub-assy, Tonneau Cover |
| 64931B | Hanger, Tonneau Cover, RH |
| 64932B | Hanger, Tonneau Cover, LH |
| 64933A | Bracket, Tonneau Cover Holder, RH |
| 64934A | Bracket, Tonneau Cover Holder, LH |
| 64935A | Holder, Tonneau Cover |
| 67921C | Retainer, Deck Trim Side Board |
| 73903 | Bracket Sub-assy, Rear Shelf, RH |
| 73904 | Bracket Sub-assy, Rear Shelf, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
