Toyota Carina 2
1987-12 → 1992-03 · chassis AT17#,ST171,CT171 · catalogue 271520 · Europe
Discontinued model
Data version 1993-08
Overdrive & Electronic Controlled Transmission
10 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 82125A | Wire, Transmission |
| 82125D | Plate, Transmission Wire Lock |
| 84220A | Switch Assy, Transmission Position Indicator |
| 84570B | Switch Assy, Kick Down |
| 84571A | Switch, Kick Down |
| 84579A | Bracket, Kick Down Switch |
| 84722 | Switch, Transmission Control |
| 85420B | Solenoid Assy, Transmission |
| 89427A | Switch, Temperature |
| 89530A | Computer Assy, Transmission Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
