Toyota Avensis
1997-10 → 2003-01 · chassis AT22#,AZT220,CDT220,CT220,ST220,ZZT22# · catalogue 273540 · Europe
Discontinued model
Data version 2003-08
Heating & Air Conditioning - Water Piping
28 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 87101A | Bracket Sub-assy, Heater NO.1 |
| 87110D | Heater Assy |
| 87110E | Heater Assy |
| 87114E | Cover, Heater, NO.1 |
| 87131A | Housing, Heater Blower |
| 87131C | Housing, Heater Blower, NO.2 |
| 87131D | Housing, Heater Blower, NO.3 |
| 87209 | Hose Sub-assy, Water |
| 87245A | Hose, Heater Water, Inlet A |
| 87245B | Hose, Heater Water, Inlet B |
| 87245C | Hose, Heater Water ,Inlet C |
| 87245D | Hose, Heater Water, Inlet D |
| 87246A | Hose, Heater Water, Outlet A |
| 87271A | Hose, Heater Vacuum, NO.1 |
| 87271B | Hose, Heater Vacuum, NO.2 |
| 87343A | Plug, Combustion Heater Glow |
| 87344D | Wiring, Heater |
| 87351 | Chamber, Fuel Regulator Body |
| 87363 | Gasket, Fuel Regulator Cover |
| 87378A | Pipe, Exhaust |
| 87392 | Housing, Motor |
| 87408A | Pump Sub-assy, Fuel |
| 87441C | Muffler |
| 87476A | Hose, Heater Fuel, NO.1 |
| 87521A | Bracket, Engine Block Heater |
| 87611 | Case, Heat Exchanger |
| 88326E | Plate, Cover |
| 88626E | Sensor, Water Temperature |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
