Toyota Avensis
2003-01 → 2008-11 · chassis ADT25#,AZT25#,CDT250,ZZT25# · catalogue 273550 · Europe
Supported model
Data version 2009-04
Suspension Crossmember & Under Cover
30 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 48971B | Bracket, Height Control Pump, NO.1 |
| 48971C | Bracket, Height Control Pump, NO.2 |
| 51201 | Crossmember Sub-assy, Front Suspension |
| 51204A | Member Sub-assy, Engine Mounting, Center |
| 51206A | Member Sub-assy, Rear Suspension |
| 51227B | Damper, Front Suspension Member Dynamic |
| 51229B | Dumper, NO.2 Frame Crossmember Dynamic |
| 51249 | Damper, Rear Suspension Member |
| 51405A | Cover Sub-assy, Engine Under, NO.1 |
| 51441C | Cover, Engine Under, RH |
| 51442C | Cover, Engine Under, LH |
| 51451 | Cover, Engine Under, NO.4 RH |
| 51963B | Hook, Transport, Front RH |
| 51967 | Hook, Transport, Rear |
| 52211J | Cushion, Front Suspension Member Body Mounting, Front |
| 52212A | Cushion, Body Mounting, NO.2 |
| 52213A | Stopper, Front Suspension Member Body Mounting, Front |
| 52215 | Cushion, Front Suspension Member Body Mounting, Rear |
| 52216B | Stopper, Front Suspension Member Body Mounting, Rear |
| 52257 | Brace, Front Suspension Member, Rear RH |
| 52258A | Brace, Front Suspension Member, Rear LH |
| 52271E | Cushion, Rear Suspension Member Body Mounting, Front RH |
| 52272 | Stopper, Rear Suspension Member, Upper |
| 52273A | Stopper, Rear Suspension Member, Lower RH |
| 52274A | Stopper, Rear Suspension Member, Lower LH |
| 52275A | Cushion, Rear Suspension Member Body Mounting, Rear |
| 52276A | Cushion, Rear Suspension Member Body Mount, Rear LH |
| 52297 | Brace, Rear Suspension Member, Rear Lower RH |
| 52298 | Brace, Rear Suspension Member, Rear Lower LH |
| 58398F | Cover, Floor Under, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
