Toyota Avensis
2008-11 → 2018-07 · chassis ADT27#,WWT27#,ZRT27# · catalogue 273560 · Europe
Supported model
Data version 2019-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 28800 — Battery | ||||
| 28800-0D350 note |
Battery
2008-11 → 2011-11
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 28800-0G050 note |
Battery
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 28800-0G050 note |
Battery
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 28800-0R040 note |
Battery
2008-11 → 2011-11
ended
|
1ADFTV ADT270 LHD SED +1 | — | |
| 28800-0R060 note |
Battery
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 28800-0R060 note |
Battery
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 28800-0T010 note |
Battery
2008-11 → 2011-11
ended
|
3ZRFE ZRT272 LHD | — | |
| 28800-0T010 note |
Battery
2008-11 → 2011-04
ended
|
3ZRFE ZRT272 RHD | — | |
| 28800-0Y010 note |
Battery
2008-11 → 2011-11
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# LHD | — | |
| 28800-0D350 note |
Battery
2011-11 → 2015-05
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 28800-0G050 note |
Battery
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 28800-0R060 note |
Battery
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 28800-0T010 note |
Battery
2011-11 → 2015-05
ended
|
3ZRFE ZRT272 | — | |
| 28800-0T060 note |
Battery
2012-11 → 2015-05
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# LHD | — | |
| 28800-0Y010 note |
Battery
2011-11 → 2012-05
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# LHD | — | |
| 28800-0D350 note |
Battery
2015-05 → 2018-01
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 28800-0D351 note |
Battery
2018-02 → —
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 28800-0R090 note |
Battery
2015-05 → —
|
1WW,2WW WWT27# | — | |
| 28800-0T010 note |
Battery
2015-05 → 2018-01
ended
|
3ZRFE ZRT272 | — | |
| 28800-0T011 note |
Battery
2018-02 → —
|
3ZRFE ZRT272 | — | |
| 28800-0T060 note |
Battery
2015-05 → 2018-01
ended
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# LHD | — | |
| 28800-0T061 note |
Battery
2018-02 → —
|
1ZRFAE,2ZRFAE,3ZRFAE ZRT27# LHD | — | |
| 28800A — Terminal, Battery Positive | ||||
| 90982-05054 |
Terminal, Battery Positive
2008-11 → 2011-11
ended
|
3ZRFE ZRT272 LHD;1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 90982-05054 |
Terminal, Battery Positive
2008-11 → 2011-04
ended
|
3ZRFE ZRT272 RHD | — | |
| 90982-05056 |
Terminal, Battery Positive
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 90982-05056 |
Terminal, Battery Positive
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 90982-05054 |
Terminal, Battery Positive
2011-11 → 2015-05
ended
|
1ZRFAE,2ZRFAE,3ZR# ZRT27# | — | |
| 90982-05056 |
Terminal, Battery Positive
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 90982-05053 |
Terminal, Battery Positive
2015-05 → —
|
1WW,2WW WWT27# | — | |
| 90982-05054 |
Terminal, Battery Positive
2015-05 → —
|
1ZRFAE,2ZRFAE,3ZR# ZRT27# | — | |
| 28800D — Cover, Connector(FOR BATTERY TERMINAL) | ||||
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2008-11 → 2011-04
ended
|
3ZRFE ZRT272 RHD | — | |
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2008-11 → 2011-11
ended
|
3ZRFE ZRT272 LHD;1ZRFAE,2ZRFAE,3ZRFAE ZRT27# | — | |
| 82821-12620 |
Cover, Connector(FOR BATTERY TERMINAL)
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 82821-12620 |
Cover, Connector(FOR BATTERY TERMINAL)
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2011-11 → 2015-05
ended
|
1ZRFAE,2ZRFAE,3ZR# ZRT27# | — | |
| 82821-12620 |
Cover, Connector(FOR BATTERY TERMINAL)
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 82821-12490 |
Cover, Connector(FOR BATTERY TERMINAL)
2015-05 → —
|
1ZRFAE,2ZRFAE,3ZR# ZRT27# | — | |
| 28800J — Terminal, Battery Negative | ||||
| 90982-06070 |
Terminal, Battery Negative
2008-11 → 2011-04
ended
|
3ZRFE ZRT272 RHD;1ADFTV ADT270 +2 | — | |
| 90982-06070 |
Terminal, Battery Negative
2008-11 → 2011-11
ended
|
1ADFTV FAE ADT270 ADT271,ZRT27# +4 | — | |
| 90982-06070 |
Terminal, Battery Negative
2011-11 → 2015-05
ended
|
1ADFTV,2AD#,1ZRFAE,2ZRFAE,3ZR# ADT27#,ZRT27# | — | |
| 90982-06070 |
Terminal, Battery Negative
2015-05 → —
|
1WW,2WW,1ZRFAE,2ZRFAE,3ZR# WWT27#,ZRT27# | — | |
| 28899 — Insulator, Battery | ||||
| 28899-26050 note |
Insulator, Battery
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 28899-26050 note |
Insulator, Battery
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 28899-26070 note |
Insulator, Battery
2008-11 → 2011-11
ended
|
1ADFTV ADT270 LHD SED +1 | — | |
| 28899-26080 |
Insulator, Battery
2008-11 → 2011-04
ended
|
1ADFTV ADT270 LHD F | — | |
| 28899-26080 |
Insulator, Battery
2008-11 → 2011-11
ended
|
2AD# ADT271;1ADFTV ADT270 RHD;1ADFTV +3 | — | |
| 28899-26050 note |
Insulator, Battery
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 28899-26080 |
Insulator, Battery
2011-11 → 2015-05
ended
|
1ADFTV,2AD# ADT27# | — | |
| 28899-26100 |
Insulator, Battery
2015-05 → —
|
1WW,2WW WWT27# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
